Fig.2 engine group, Bc2600le – Zenoah BC340WE User Manual
Page 13
Fig.2 ENGINE GROUP
1
5910-12110
CYLINDER
1
2
5500-12211
GASKET,base
1
3
1850-12130
BOLT
2
4
1920-13162
INSULATOR
1
5
5500-13120
GASKET,insulator
1
6
5500-13130
GASKET,carburetor
1
7
00263-90520
SCREW
2
8
5580-15110
MUFFLER
1
9
01252-30550
BOLT
2
10
5500-15210
GASKET
1
11
5500-15220
PLATE
1
12
00263-90416
SCREW
1
13
5500-21100
CRANKCASE COMP
1
14
5500-21140
GASKET,case
1
15
06030-06001
BEARING
2
16
2169-21210
OIL SEAL
1
17
1850-21220
OIL SEAL
1
18
04065-02812
SNAP RING
1
19
01252-30530
BOLT
4
20
00263-90514
SCREW
1
21
5910-41110
PISTON
1
22
5910-41210
RING
2
23
1600-41310
PIN
1
24
1260-41320
SNAP RING
2
25
1140-41330
BEARING
1
26
1101-41340
WASHER
2
27
5500-42001
CRANKSHAFT COMP
1
28
1650-43230
NUT
1
29
1000-43240
KEY
1
30
1400-51111
SHOE
2
31
1140-51250
SCREW
2
32
1970-51221
SPRING
1
33
1140-51230
WASHER
1
34
1970-51241
WASHER
1
35
5501-71110
ROTOR
1
36
5501-71201
COIL ASSY
1
37
5500-71220
• CORD,high
1
38
2616-71320
• CAP
1
39
1900-72111
CAP
1
40
1900-72120
SPRING
1
41
5500-72130
GROMMET
1
42
1260-71261
SPACER
2
43
3310-72150
BOLT
2
44
5500-75000
STARTER ASSY
1
45
5500-75100
• RECOIL ASSY
1
46
1850-75120
• • REEL
1
47
1850-75130
• • SPIRING,spairal
1
48
1850-75151
• • SCREW
1
49
1850-75160
• • ROPE
1
50
1140-75320
• • KNOB
1
51
5500-75170
• • TAPE
1
52
1850-75201
• PULLEY ASSY
1
53
1850-75221
• • RATCHET
1
54
1850-75230
• • SPRING
1
55
00263-90416
SCREW
4
56
5912-81000
CARBRETOR ASSY
1
57
1850-81450
• BODY ASSY
1
58
3306-81380
• • SCREEN
1
59
3356-81310
• • VALVE
1
60
1850-81270
• • SPRING
1
61
1850-81220
• • SCREW
1
62
3310-81250
• • PIN
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
63
3310-81230
• • LEVER
1
64
1850-81490
• BODY
1
65
1850-81520
• COVER
1
66
1751-81510
• PUMP
1
67
3310-81260
• DIAPHRAGM ASSY
1
68
1850-81470
• GASKET
1
69
1065-81420
• DIAPHRAGM
1
70
1065-81410
• GASKET
1
71
1850-81251
• JET
1
72
1751-81240
• O-RING
4
73
1751-81130
• RING
2
74
5500-81160
• WASHER
1
75
1881-81140
• SWIVEL
1
76
5500-81152
• VALVE ASSY
1
77
1752-81110
• SCREW
2
78
5500-81120
• BRAKET
1
79
1751-81180
• NUT
1
80
1918-81170
• SCREW
1
81
1881-81130
• RING
1
82
1850-81530
• SCREW
1
83
00263-30555
SCREW
2
84
1950-86120
CLIP
1
85
5500-82102
BODY ASSY
1
86
1970-82190
• SLEEVE
2
87
5500-82131
• PLATE
1
88
5500-82140
• LVEVER
1
89
2630-33610
• SCREW
1
90
5500-82171
ELEMENT
1
91
5600-82201
COVER ASSY
1
92
5500-82221
• KNOB
1
93
5500-82230
• RING
1
94
5501-31111
COVER
1
95
00263-90520
SCREW
4
96
5580-32111
COVER
1
97
1850-32160
SCREW
1
98
1900-31410
SCREW
2
99
5500-32210
GUARD
1
100
00263-90514
SCREW
1
101
5602-73110
SPARKPLUG
1
Champion RCJ-6Y
102
1852-72120
GROMMET
1
103
5500-73201
CORD COMP
1
104
1140-72231
CLAMP
1
105
5912-85001
TANK ASSY
1
106
5504-85201
• CAP ASSY
1
107
5500-85220
• • PACKING
1
108
3317-57242
• • STOPPER
1
109
5500-85602
• BREATHER ASSY
1
110
1950-86120
• • CLIP
1
111
5911-85300
• PIPE COMP
1
112
5500-85400
• FILTER ASSY
1
113
1260-85460
• CLIP
1
114
5500-85510
SCREW
2
115
5910-85510
SCREW
1
116
1140-72231
CLAMP
1
117
5912-91120
LABEL,recoil
1
118
5500-91130
LABEL,cover
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
BC2600LE
