Zenoah BC340WE - Manual (Page 17)

Fig.1 CUTTER GROUP
1 3531-11001 HOUSING ASSY 1
2 3531-11101 • HOUSING COMP 1
3 3531-11131 • CLAMP-L 1
4 3531-11141 • CLAMP-R 1
5 3350-21320 • BOLT 2
6 3530-11310 • DRUM 1
7 06004-06202 • BEARING 1
8 04065-03515 • RING 1
9 04064-01510 • RING 1
10 6039-11300 PIPE COMP 1
11 3520-12212 SHAFT 1
12 3530-13906 GEARCASE ASSY 1
13 3541-13194 • GEARCASE 1
14 06000-06000 • BEARING 1
15 06000-06201 • BEARING 1
16 04065-03212 • RING 1
17 3180-13141 • SEAL 1
18 3541-13212 • SHAFT,gear 1
19 3180-13220 • GEAR 1
20 3579-33260 • BOLT 1
21 01643-30823 • WASHER 1
22 3310-43210 • WASHER 1
23 3530-13311 • PINION 1
24 06001-06000 • BEARING 1
25 06000-06000 • BEARING 1
26 3180-13330 • RING 1
27 04065-02612 • RING 1
28 01252-30510 • BOLT 1
29 3540-13260 • BOLT 1
30 3541-13241 • HOLDER(A) 1
31 3541-13251 • HOLDER(B) 1
32 00224-40610 • BOLT 1
33 3520-13284 COVER 1
34 9366-17100 HANGER ASSY 1
35 9366-17110 • HANGER 1
36 9366-17120 • CLAMP 1
37 00263-90525 • SCREW 1
38 3530-14900 BRACKET ASSY 1
39 3540-14900 • BRACKET ASSY 1
40 3540-14910 • • BRACKET 1
41 3540-14920 • • CAP-L 1
42 3540-14930 • • CAP-U 1
43 3540-14140 • • ABSORBER 2
44 3450-14150 • • CLAMP-A 1
45 3540-14160 • • CLAMP-B 1
46 01252-30525 • • BOLT 6
47 01252-30530 • • BOLT 4
48 3530-14171 • SPACER 2
49 6465-14200 HANDLE-L 1
50 6350-14230 HANDLE-R 1
51 5765-12510 PLATE,name 1
52 6425-12552 PLATE,caution 1
53 5765-24000 GUARD ASSY 1
54 5766-24110 • GUARD 1
55 3253-24120 • BRACKET 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
56 00225-10620 • BOLT 2
57 00263-30614 • SCREW 4
58 00280-10605 • NUT 4
59 6298-14243 SAW 1
60 6220-17201 HARNESS ASSY 1
61 6251-15910 COVER,blade 1
62 6468-91150 BOLT 4
63 6242-92110 GOGGLE 1
64 3532-91000 TOOL SET 1
65 1030-91340 • DRIVER 1
66 3239-91310 • SOCKET 1
67 09007-00425 • WRENCH 1
68 09007-00528 • WRENCH 1
69 3540-91120 • SPANNER 1
70 3540-91110 • BAR 1
71 3523-17112 PROTECTOR 1
72 3540-93120 BAND 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
BC340WE
