Zenoah BC340WE - Manual (Page 11)

Fig.1 CUTTER GROUP
1 6574-11000 HOUSING ASSY 1
2 6470-11110 • HOUSING 1
3 6460-11130 • CLAMP-L 1
4 6460-11140 • CLAMP-R 1
5 3350-21320 • BOLT 2
6 6460-12110 • DRUM 1
7 06004-06001 • BEARING 1
8 04065-02812 • RING 1
9 04064-01210 • RING 1
10 6038-11301 PIPE COMP 1
11 6784-12210 SHAFT 1
12 6440-13002 GEARCASE ASSY 1
13 6440-13122 • GEARCASE 1
14 06000-00626 • BEARING 1
15 06000-06000 • BEARING 1
16 04065-02612 • RING 1
17 3565-13130 • SEAL 1
18 6440-13211 • SHAFT,gear 1
19 6440-13220 • GEAR 1
20 3560-13261 • BOLT 1
21 3560-13290 • WASHER 1
22 6440-13311 • PINION 1
23 06001-00609 • BEARING 1
24 06000-00609 • BEARING 1
25 3210-13330 • RING 1
26 04065-02412 • RING 1
27 01252-30510 • BOLT 1
28 3350-21320 • BOLT 1
29 6440-13242 • HOLDER(A) 1
30 6019-13250 • HOLDER(B) 1
31 00224-40610 • BOLT 1
32 6420-13280 COVER 1
33 6423-11330 GRIP ASSY 1
34 6464-12210 • GRIP(R) 1
35 6464-12220 • GRIP(L) 1
36 6464-12230 • LEVER 1
37 1638-84170 • SPRING 1
38 6464-12240 • LEVER 1
39 1638-84180 • SPRING 1
40 6423-12230 • SWITH COMP 1
41 6423-11390 • CABELE COMP 1
42 6423-12430 • CORD COMP 1
43 1638-84150 • STOPPER 1
44 1638-84220 • SCREW 4
45 6464-12250 • CLAMP 1
46 1638-84160 • CLAMP 1
47 00263-60620 • SCREW 2
48 1638-84190 • NUT 2
49 6130-18000 HANGER ASSY 1
50 6130-18101 • HANGER 1
51 6130-18200 • CLAMP 1
52 00263-90520 • SCREW 1
53 5764-12510 PLATE,name 1
54 6425-12552 PLATE,caution 1
55 6420-14100 HANDLE ASSY 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
56 6420-14311 • HANDLE 1
57 6420-14320 • CLAMP 1
58 00263-90535 • SCREW 4
59 5764-24000 GUARD ASSY 1
60 5766-24110 • GUARD 1
61 3250-24120 • BRACKET 1
62 00225-10620 • BOLT 2
63 00263-30614 • SCREW 4
64 00280-10605 • NUT 4
65 6298-14243 SAW 1
66 6489-17200 STRAP ASSY 1
67 6251-15910 COVER,blade 1
68 6468-91150 BOLT 1
69 6242-92110 GOGGLE 1
70 3550-91000 TOOL SET 1
71 1030-91340 • DRIVER 1
72 3239-91310 • SOCKET 1
73 09007-00425 • WRENCH 1
74 3540-91120 • SPANNER 1
75 3540-91110 • BAR 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
BC2600LE
