Cards installable on the AI8 analog input box:
•
LMY2-ML, LMY2-MLAB,
LMY4-MLF
: MIC/LINE input card
•
LMY4-AD
:
AD card
Up to eight cards can be installed.
Unit models:
•
AI8-ML8AB
: AI8 analog input box that has eight
LMY2-MLAB cards installed
•
AI8-ML8F
:
AI8 analog input box that has eight
LMY4-MLF cards installed
•
AI8-AD8
:
AI8 analog input box that has eight
LMY4-AD cards installed
■
Front panel
■
Rear panel
Thank you for choosing the AI8 analog input box, the AI8-ML8AB/AI8-ML8F mic line input unit, or the
AI8-AD8 AD unit, specifically designed for the Yamaha PM1D digital audio mixing system.
The AI8 inputs signals to the DSP unit DSP1D/DSP1D-EX engine (controlled via the CS1D control sur-
face). Up to ten AI8s can be connected to each DSP1D/DSP1D-EX.
Be sure to ask an authorized Yamaha service engineer to install the card and set up the unit.
Never perform installation and setup by yourself.
UNIT NO.
PHANTOM MASTER
ON
OFF
+48V
POWER
ON/ OFF
1
2
3
4
5
6
7
8
ANALOG INPUT BOX
1
2
3
INPUT UNIT ID
PHANTOM MASTER
ON
OFF
+48V
POWER
ON/ OFF
ANALOG INPUT BOX
The illustration shows the AI8
