17
CONTROLS
Refueling
The machine has two fuel tanks, one on each
side just behind the seat. The tanks hold 11.4
gallons, 5.7 gallons each.
The engine is run on clean, fresh, diesel fuel
with a minumum of 40 cetane.
.
Fuel Shut-Off
The fuel shut-off is placed to the right side of
the seat. The shut-off has three positions;
right tank, left tank and off position.
Fuses
The fuses are located in a fuse block to the
right of the battery. They are flat pin fuses of
the same type used in automobiles.
There are five fuses.
Fuse ratings and functions moving from the
top:
• 20A - accesory jack
• 7.5A - sub system
• 10A - PTO/clutch
• 30A - hydrualic deck lift
• 50A - main system fuse (in line)
Fuel Tanks BAM-8
WARNING!
Diesel fuel is highly
flammable. Observe caution
and fill the tank outdoors
(see the safety rules).
Fuel Shut-Off BAM-9
Fuses
20A
7.5A
30A
50A
10A
BAM-10
