22
Technical Data
Dimensions of recess
Height undertop: 593 mm; in coloumn 580 mm
Width 560 ÷ 570 mm
Depth 550 mm
Dimensions of the oven cavity
Height 335 mm
Width 405 mm
Depth 400 mm
Oven capacity 56 litres
This oven must be installed by qualified
personnel. The oven must be installed according to the
instructions supplied.
Installation
Heating elements rating
Oven element 1,880 W
Top element 835 W
Bottom element 1,045 W
Convection element 2,090 W
Grill element 1,795 W
Double Grill element 2,665 W
Pizza Oven Function 3,135 W
Convection Fan 30 W
Oven Light 40 W
Cooling Fan 25 W
Total Rating 3,200 W
Supply voltage (50 Hz) 230-240 V
Electrical connection
The oven is designed to be connected to 230-240 V (50
Hz) electricity supply.
The oven has an easily accessible terminal block which
is marked as follows:
Letter L - Live terminal
Letter N - Neutral terminal
or E - Earth terminal
THIS OVEN MUST BE EARTHED
The cable used to connect the oven to the electrical
supply must comply to the specifications given below.
It is necessary that you install a double pole switch
between the oven and the electricity supply (mains), with
a minimum gap of 3mm between the switch contacts
and of a type suitable for the required load in compliance
with the current rules.
The switch must not break the yellow and green earth
cable at any point.
Important
After installation and connecting, the cable must be
placed so that it cannot at any point reach a temperatu-
re of more than 60 °C above the ambient temperature.
Before the oven is connected, check that the main fuse
and the domestic installation can support the load; and
that the power supply is properly earthed.
The manufacturer disclaims any responsibility should
these safety measures not be carried out.
Connection Min. size Cable / flex Fuse
via Cable/flex type
• Cooker 2.5 mm 2 PVC/PVC 20 A
Control twin and
Circuit earth
For Uk use only
For Europe use only
Min. size Cable/flex Cable / flex type Fuse
2.5 mm 2 H07 RN-F, H05 RN-F, 15 A
H05 RR-F, H05 VV-F,
H05 V2V2-F (T90),
H05 BB-F
