6
OVERALL DIMENSIONS
Width: 580 mm.
Depth: 510 mm.
Height: 88 mm.
Weight: 9,8 Kg.
Instructions for the Installer
CUT OUT DIMENSIONS
Width: 550 mm.
Depth: 470 mm.
Thickness: 40 mm.
Supply Connections
Gas:
RC 1/2 inch (1/2 inch male) Rear right hand
corner
Electric:
230-V 50Hz supply, 3 core flexible cable with
non rewireable plug.
Appliance Gas supply: LPG 30 mbar
Appliance Class: 3
Appliance category: I 3
Engineer technical data
Burner Nominal Power LPG (Butane "A") Diameter Feeding
Tap. By-Pass Tap colour Pressure
kW kCal/h Nozzle gh mbar (*)
Auxiliary (dia. 42 mm.) 0,95 814 50 75 28 Red/Yellow
Semi-rapid (dia. 57 mm.) 1,60 1368 65 126 35 Brown/Black 30
Rapid (dia. 90 mm.) 2,45 2095 80 193 45 Blue/Yellow
(*) 1 mbar = 10 mm. water coloumn.
Something Not Working?
If the appliance is not working correctly, please carry out the following checks before contacting your
local
Service Centre.
SYMPTOM
There is no spark when lighting the gas
The gas ring burns unevenly
SOLUTION
Check that the unit is plugged in and the
electrical supply is switched on
Check that the RCCB has not tripped (if
fitted)
Check the burner cap and crown have been
replaced correctly, e.g. after cleaning.
Check the main jet is not blocked and the
burner crown is clear of food particles.
Check the burner cap and crown have been
replaced correctly, e.g. after cleaning.
If after all these checks, your appliance still
does not operate correctly, contact your local
Service Centre.
