Description of the appliance – Zanussi ZGG649 User Manual
Page 4
4
Description of the Appliance
INSTALLATION
Any gas installation must be carried out
by qualified personnel, and in
accordance with existing rules and
regulations.
The relevant instructions are to be found in the
second section of this manual.
Please, ensure that, once the
appliance is installed, it is easily
accessible for the engineer in the event
of a breakdown.
WHEN THE HOB IS FIRST
INSTALLED
Once the hob has been installed, it is
important to remove any protective
materials, which were put on in the
factory.
1. Hob Top
2. Rapid Burner
3. Semi-rapid Burners
4. Auxiliary Burner
5. Control knob for back right burner (semi-rapid)
6. Control knob for back left burner (semi-rapid)
7. Control knob for front left burner (rapid)
8. Control knob for front right burner (auxiliary)
1
3
5
6
7
8
4
2
