System Connection Examples
You can use a CobraNet interface unit such as the NHB32-C to make a bridge connection from a CobraNet net-
work to an AES/EBU signal.
Bridge connections from CobraNet to AES/EBU
Network switch
Amp control
TXn
Amp Editor
Computer
Amp control
Amp control
Amp control
TXn
TXn
IN
CobraNet
network
NHB32-C
IN
IN
AES/EBU
AES/EBU
CobraNet
AES/EBU
