1 Open the door fully
and hold the two door
hinges.
2 Lift and turn the levers
on the two hinges.
3 Close the oven door to
the first opening position
(halfway). Then pull for-
ward and remove it from
its seat. Place the door on
a stable surface protected
by a soft cloth.
4 Place the door on a
stable surface protected
by a soft cloth.
5 Release the locking
system to remove the in-
ternal panel of glass.
90°
6 Turn 2 fasteners by
90° and remove them from
their seats.
1
2
7 Carefully lift and re-
move the panel of glass.
Clean the glass panel with water and soap. Dry the glass
panel carefully.
Installing the door and the glass panel
After cleaning, install the glass panel in opposite order.
Make sure that when you install the internal panel with a
decorative frame, the screen-printing is on the outer side.
Make sure that the surface of the glass panel frame is not
rough when you touch it.
Make sure that you put the internal panel of glass to the
correct seats (refer to the picture).
Replacing the oven light bulb/cleaning the glass
cover
Warning! Be careful! There is the risk of electrical
shock!
1. Turn the glass cover anti-clockwise to remove it.
2. Clean the glass cover.
3. Replace the oven light bulb with applicable 300°C
heat-resistant oven light bulb. New oven light bulb
must have the same parameters as your previous one.
4. Install the glass cover.
What to do if…
Warning! Refer to "Safety information" chapter.
