SECTION 5: UNPACKING INSTRUCTIONS
REMOVE UNIT FROM CARTON
(See Figure 3.)
• Remove staples, break glue on top flaps, or cut tape at carton end and peel along top flap to open carton.
• Remove loose parts if included with unit (i.e., operator’s manual, etc.).
• Cut along dotted lines and lay carton down flat.
• Remove packing material.
• Roll or slide unit out of carton. Check carton thoroughly for loose parts.
Figure 3
DISCONNECT SPARK PLUG WIRE
Before setting up your lawn mower, disconnect the spark plug wire from the spark plug, and ground it against the
engine by attaching rubber boot to a bolt or metal clip to the grounding post on the engine. See Figure 4.
Figure 4
PUSH
REMOVE MANUAL & LOOSE PARTS
Spark Plug
Spark Plug
Wire
