Model 979 – Yard-Man 247.37979 User Manual
Page 25
25
Model 979
Ref.
No.
Part No.
Description
Ref.
No.
Part No.
Description
1
710-0134
Scr. Carr. 1/4-20 x .62
40
731-1901
Trail Shield
2
710-0654A
Scr. TT:3/8-18:1.00
41
732-0842
Trail Shield Wire
3
710-0703
Scr. 1/4-20 x .750
42
611-0064-0665
Fr. Axle Ass’y.
4
712-0397
Wing Nut 1/4-20
43
710-1241
Hx Scr. Wash Hd. Hi.-Lo.
5
723-0233
Nut, Push .25 I.D. x .50 O.D.
44
710-1242
Scr. Torx, Truss Hi.-Lo.
6
736-0204
Wash. Fl. .334 I.D.x .62 x.03
45
714-0104
Cotter Pin .072 x 1.12 Lg.
7
782-0046A-0665
Deck - 21”
46
731-1829
Fr. Axle Cover, Yellow
8
710-0653
Scr. TT. 1/4-20 x .375
47
736-0286
Bowed Washer
9
710-0969
Scr. HL. 1/2-14 x .750
48
741-0492A
Bush. Block .505 Dia. x .62
10
731-1828
Baffle
49
782-0565-0665
Control Arm
11
638-0012
Rear Axle Ass’y
50
734-1978
Wheel 8 x 2 Link, Yellow
12
682-0531
Pivot Arm Ass’y
51
734-1981
Wheel 9 x 2 Link Yellow, Slv.
13
682-7526
Trans. Axle Ass’y
52
736-0105
Spr. Wash. .401 x .870 x .063
14
682-7528
Chain Cover Ass’y
53
736-0504
Wave Wash .510 x .750 x .017
15
710-0653
Scr. TT 1/4-20 x .375
54
738-0102
Shld. Scr .498 x 1.445 x3/8-16
16
710-0751
Cap Screw HH 1/4-20 x .620
55
10622B
Spring, Ratchet, Plastic
17
710-0896
Scr. AB 1/4-14 x .625
56
748-0381
Pawl - R.H.
18
710-1315
Scr. 3/8 116 x .25
748-0188B
Pawl - L.H. (Not Illustrated)
19
711-0835
Clevis Pin .50 Dia. x 4.82 Lg.
58
16855
Ratchet Pawl Plate
20
713-0453
Chain-Endls. #48 .500P x 24L
59
738-0137A
Scr. Shld. .340 x .285
21
714-0474
Cotter Pin .125O.D. x .75
60
712-0414
Top Lock Tab Weld Nut 1/4-20
22
720-0223
Grip
61
731-1426
Hubcap -Yellow
23
732-0803A
Spring Lever
64
725-0157
Cable Tie
24
732-0832
Torsion Spring
65
710-0604
Hex Scr. 5/16-18
25
736-0270
Bell Wash. .285 x .75 x .082
66
754-0460
V-Belt
26
736-0369
Fl. Wash..508 I.D. 1.000 x.020
67
742-0741
21” Mulching Blade
27
738-0529
Nut Shld. .825 Dia. x .165 Lg.
68
753-0609
Blade Adapter Kit
28
741-0324
Hx.Flg. Brg..506 I.D. x .590 L.
69
736-0524A
Blade Bell Suport
29
741-0522
Hx.Flg. Brg. .506 I.D. x.715 L.
70
710-1257
Hex Bolt 3/8-24x2.5”Lg.
30
741-0978
Hx. Slv. Brg..504 I.D. x .830 L.
72
735-0639
Spark Plug Insulator
31
748-0318
Wheel Rachet
73
731-1832
Side Discharge Chute
32
750-0151
Spa. .550 I.D. x /750 O.D.
74
731-1833
Mulch Cover
33
750-0515
Spa. .51 .D. x .70 O.D. x 38 L.
75
631-0066
Chute Ass’y
34
750-0807
Spa. .385 x .624 x .700
76
731-1713A
Discharge Chute
35
750-1056
Shld. Spa. .385 I.D. X .715 Lg.
77
747-0965
Pivot Rod
36
782-0568
Brkt. - Ht. Adj. Spring
78
732-0819
Torsion Spring
37
682-3052A-0665
Handle Brkt. Ass’y. R.H.
79
726-0111
Push Cap
38
682-3053A-0665
Handle Brkt. Ass’y. L.H.
80
731-1874
Chute Door
39
710-1348
Scr. AB 1/4-14 x .500
