28
Model 979
Ref.
No.
Part No. Code Description
1 746-0939 6 Spd. Cable
2 656-0613 Pulley Ass’y Multi- Spd.
3 710-0167 Scr. 1/4-20 x .50 Carr.
4 710-0896 Scr. AB 1/4-14 x .625 Hxinwsh
5 711-1114 Pivot Shaft
6 712-0287 Nut 1/4-20
7 732-0807 Torsion Spring LH
8 736-0270 Bell Wash. .265 X .75 X .062
9 736-0329 Lock Wash. 1/4 Reg Duty
10 736-0526 Wave Wash. 1.38 x .88 x .029
11 738-0924 Shld.Scr. .375 x1/4-14AB
12 750-1070 Slev Spcr .88 IDx1.00 OD x.48
13 750-1071 Slev Spcr .88ID x1.13ID x .12
14 756-0625 Roller Cable
15 782-7574-0665 6 Spd. Cable Adj. Bracket
16 782-7575-0665 6 Spd. Cable Mt. Bracket
17 782-7596 6 Sp. Control Arm
18 782-7597 6 Sp. Pivot Bracket
19 712-0138 Hex Nut 1/4-28
15
2
8
1
4
11
3
13
10
12
17
18
5
7
16
14
6
9
19
