41
Hum&Noise fs=48kHz or 96kHz, EIN=Equivalent Input Noise
Dynamic Range fs=48kHz or 96kHz
Crosstalk@1kHz reference to the level of output N
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600
Ω
Rs=150
Ω
, GAIN: –60dB
All input & output level controls: 0dB
–128
EIN
–127
EIN
dBu
–64 dBu
Rs=150
Ω
, GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600
Ω
Rs=150 Ω , GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–4 OUTPUT 1–4 600 Ω
Rs=150
Ω
, GAIN: –60dB
All input & output level controls: 0dB
–128
EIN
–127
EIN
dBu
–64 dBu
Rs=150
Ω, GAIN: +10dB
All input & output level controls: 0dB
–82 –79 dBu
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with
infinite dB/octave attenuation.
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–8 OUTPUT 1–8 600
Ω
GAIN: +10dB 106 dB
Input Output RL CONDITIONS MIN TYP MAX UNITS
INPUT 1–4 OUTPUT 1–4 600 Ω GAIN: +10dB 106 dB
* Dynamic range are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with
infinite dB/octave attenuation.
from to CONDITIONS MIN TYP MAX UNITS
INPUT N OUTPUT (N–1) or (N+1) N = 1–8, GAIN: +10dB –80 dB
from to CONDITIONS MIN TYP MAX UNITS
INPUT N OUTPUT (N–1) or (N+1) N = 1–4, GAIN: +10dB –80 dB
* Crosstalk is measured with a 18dB/octave filter @80kHz
