Prestige 1100 Internet Access Router
13-4 IP Policy Routing
Table 13-1 IP Routing Policy Summary
Abbreviation Meaning
Criteria
SA Source IP address
SP Source port
DA Destination IP address
DP Destination port
P IP layer 4 protocol number(TCP=6,UDP=17…)
T Type Of Service of Incoming packet
PR Precedence of incoming packet
Action
GW Gateway IP address
T Outgoing Type of Service
P Outgoing Precedence
Type Of Service
NM Normal
m D Minimum Delay
MT Maximum Throughput
MR Maximum Reliability
MC Minimum Cost
Enter a number from 1 to 6 to display Menu 25.1.1 – IP Routing Policy (see the next figure). This menu
allows you to configure a policy rule.
Figure 13-3 IP Routing Policy
Menu 25.1.1 - IP Routing Policy
Policy Set Name= test
Active= Yes
Criteria:
IP Protocol = 6
Type of Service= Normal Packet length= 40
Precedence = 0 Len Comp=
Source:
addr start= 1.1.1.1 end= 1.1.1.1
port start= 20 end= 20
Destination:
addr start= 2.2.2.2 end= 2.2.2.2
port start= 20 end= 20
Action= Matched
Gateway addr = 192.168.1.1 Log= No
Type of Service= Max Thruput
Precedence = 0
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
