Figure 1-5 usb cable connectors -5, Figure 1-6 splitter -5 – ZyXEL Communications 630 User Manual
Page 17
Prestige 630 ADSL USB Modem
Connect this cable end to your modem. Connect this cable end to your computer.
Figure 1-5 USB Cable Connectors
Step 2. Use a telephone wire to connect the ADSL port to a telephone wall jack.
You may opt to buy a telephone microfilter to install between the wall jack and
your telephone(s). A microfilter acts as a low pass filter that screens out possible
interference.
Use a splitter (optional) in order to plug a phone into the same telephone line. See the following figure.
Figure 1-6 Splitter
Configuring Your Macintosh for Internet Access
1-5
