Xerox DocuColor 7000AP - Manual (Page 8)

Resolution
2400 x 2400 dpi (1-bit depth) •
Line Screens: •
150 Clustered Dot –
200 Clustered Dot –
300 Clustered Dot –
600 Clustered Dot –
200 Rotated Line Screen –
Stochastic –
Technology
Customizable Electronic Aligner Adjustments •
Custom Paper Setup •
Charge Corotron Cleaning Assembly •
Imaging System with VCSEL Technology •
Enhanced Feeding and Finishing •
Customer Service Platform • ®
Floating Aligner Transport for tight front-to-back •
registration of +/- .5 mm
7000AP/8000AP Productivity/Print
Speeds—AWM*
70/80 ppm (8.5" x 11", A4), 60 – 300 g/m • 2 , (16 lb.
Bond to 110 lb. Cover)
4200/4800 full process color A4 (letter) 4/0
•
impressions per hour
2100/2400 SRA3 (tabloid) 4/0 impressions per hour
•
Paper Format/Sizes
Maximum Sheet Size 12.6" x 19.2" (320 x 488 mm) •
Minimum Sheet Size 7.2" x 7.2" (182 x 182 mm) •
Maximum Imageable Area 12.4" x 18.9" •
(315 x 480 mm)
Paper Flexibility/Weights
Coated and uncoated papers, bright papers, •
carbonless paper, DocuCard ® , labels, business cards,
glossy brochures, window decals, durable/synthetic
papers, greeting cards, polyesters, and custom solutions
Mixed-stock jobs supported
•
16 lb. Bond/60 g/m • 2 up to 110 lb. Cover/300 g/m 2
Paper Capacity and Handling
Paper trays—2,000 sheets each, 7.2" x 7.2" •
(182 x 182 mm) to 12.6" x 19.2" (320 x 488 mm),
16 lb. Bond to 110 lb. Cover (60 to 300 g/m
2 )
Note: Tray capacity is based on 24 lb. (90 g/m 2 )
substrate
Automatic Tray Switching
•
Offsetting Output Tray: •
500 sheets with automatic offsetting sets –
Duplex:
•
automatic duplexing (4/4 impressions) from all –
trays up to 110 lb. Cover (300 g/m 2 )
Options
4,000-sheet Secondary Feeder Module •
3,750-sheet High-Capacity Stacker (HCS) •
2,250-sheet Stacker Stapler •
Xerox • ® Productivity Plus
Xerox • ® FreeFlow ® Scanner 665E
Xerox • ® DB 120-D
GBC • ® FusionPunch ® II
Standard Horizon ColorWorks 8000 •
Choice of Color Servers
Xerox • ® FreeFlow ® Print Server
Xerox • ® EX Print Server, Powered by Fiery ®
Xerox • ® CX Print Server, Powered by Creo ®
Electrical
Base Configuration: 200-240 VAC, 50/60 Hz, 30A •
(sole use)
Additional electrical required for print server,
•
feeding/finishing devices, and scanner:
115 VAC 15 Amp for 60 Hz or 220 VAC 10 Amp –
for 50 Hz (Western Hemisphere)
200–240 Volts, 10 Amp, 50 Hz (Europe)
–
Size
Base Printing System (without RIP and/or feeding/ •
finishing devices):
100" (W) x 44" (L) x 56" (H) –
2,540 mm (W) x 1,105 mm (L) x 1,413 mm (H) –
Weight: 2,200 lbs. (1,000 kg) –
Duty Cycle
DocuColor ® 8000AP
Average Monthly Volume: •
100,000 to 400,000 –
Duty Cycle:
•
1.2 million –
DocuColor ® 7000AP
Average Monthly Volume: •
75,000 to 300,000 –
Duty Cycle:
•
1.0 million –
Automated Color Quality Suite
(Optional with FreeFlow ® Print Server)
Increases productivity and consistency by •
automating calibration and color adjustments
Ensures superior image quality and repeatability
•
Reads color data at rated speed with a built-in Inline •
Spectrophotometer
Features Spot Color Calibration to automatically
•
adjust Pantone ® colors for improved accuracy
Optional FreeFlow ® Collection
FreeFlow • ® Print Manager
FreeFlow • ® Process Manager™
FreeFlow • ® Output Manager™
FreeFlow • ® Web Services, powered by Press-sense™
FreeFlow • ® VI Suite
FreeFlow • ® Makeready ®
© 2008 Xerox Corporation. All rights reserved. Xerox®, the sphere of connectivity design, Customer Service Platform®, DocuCard®, DocuColor®,
FreeFlow®, FreeFlow Makeready®, FreeFlow Output Manager™, and FreeFlow Process Manager™ are trademarks of or licensed to Xerox
Corporation in the United States and/or other countries.
GBC® and FusionPunch® are trademarks of GBC. Powered by Fiery® and ColorWise® are trademarks of Electronics for Imaging, Inc. Powered by
Creo® is a trademark of Creo, Inc. Pantone® is a trademark of Pantone Systems, Inc. Press-sense™ is a trademark of Press-sense Ltd. 12/08
610P729862
Xerox ® DocuColor ® 7000AP/8000AP
Digital Presses
For more information, call 1-800 ASK XEROX or visit us on the Web at www.xerox.com.
*All weights mode
