HANDY UNIVERSAL WRITER
MODEL LP-48
This advanced, portable unit is competitively
priced and supports: EPROMs, EEPROMs,
FLASH EPROMs, Serial E/EPROMs, NV
RAMs, Micro-Controllers, DSP, PLDs...
• Comes complete with USB cable, CD-ROM soft-
ware and power adapter
• 48 Pin ZIF socket accepts DIP devices up to 48
pins, and both 200-600 mil width
• Fast programming – takes only 30 seconds for 16M bit FLASH memory
device
• Easy to operate software with automatic processing function
• Supports low voltage components
• System Requirements: Windows (9X/ME/2000/NT/XP. Pentium II, min.
32 MB RAM but 64 MB recommended, 30MB free drive hard drive
space.
• Optional Accessories:
IC Adaptors: SOP, TSOP, SSOP, VSOP, SDIP, PLCC, QFP, µBGA.
Approximately 2 weeks delivery on adapters
Part No. 01LP48 • Price: $650.00
PROGRAMMER
USB INTERFACE – MODEL 844USB
Great common device programmer.
Reads, copies and programs IC’s via
USB computer interface
• 40 pin dual-in-line zif socket accepts both
300 and 600 mil devices up to 40 pins.
• In circuit serial programming (ISP) capability.
• Easy-to-Use. Windows 95/98/ME/NT/2000/XP compatible.
Part No. 01BK844USB • Price: $450.00
This board can program a wide range of
Microchip® PIC™ microcontrollers
Suitable for the programming of the
"VM142" mini PLC microcontroller
• Onboard configurable 40 pin. ZIF
socket
• Microcontroller selection using patch
jumper
• Easy to use programming
PICprog2006™ software included
• SUBD connector set included
• Minimum system requirements:
PIC PROGRAMMER BOARD KIT
SPECIFICATIONS
• Power supply (required): 15V DC, min. 300mA adapter
• Serial port connector: 9 p. SUBD
• Dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"
• Currently supported controllers:
Part No. 32VK8076 • Price: $41.95
• IBM Compatible PC, Pen-
tium or better
• Windows™ NT/2000/XP
• CDROM drive
• Free serial RS232 port
required
— PIC10F200
— PIC12C508A,PIC12CE518
— PIC12F629,PIC12F675
— PIC16F54
— PIC16F84A
— PIC16F870,PIC16F871,PIC16F
872,PIC16F873,PIC16F874
— PIC16F876,PIC16F877
— PIC16F627,PIC16F627A,
PIC16F628,PIC16F628A
— PIC16F648A
PIC16F630,PIC16F676
— PIC18F2550,...
PROGRAMMERS / TRAINERS
PC BASED UNIVERSAL
PROGRAMMER AND TESTER
Part No. Price
01ALL-11C2 $875.00
01ALL-11P3 1,075.00
• Supports over 12,000 IC’s including expansive array of EPROM,
EEPROM, Flash, Serial PROM, BPROM, MPU/MCU/DSP, micro-
controllers from Atmel, Dallas, Hitachi, Intel, Microchip, Mitsubishi,
Motorola, NEC, Philips, TI, Toshiba, WSI, Zilog and others.
• Supports PAL, GAL, PEEL, EPLD, EPL, FPGA, CPLD from
Altera, AMD, Atmel, Lattice, Lucent Technologies, Motorola, TI,
Xilinx, etc.
• Nearly all devices with 8-40 pins can be programmed directly
by the 40 pin ZIF socket. Adapters and converters are available
to support nearly every type of IC package including PLCC,
SOP, TSOP, QFP, TQFP, PGA, AOJ and many more.
• Can test logic IC’s, SIP/SIMM, performs functional vector tests
on programmable logic devices as fast as 4ns.
• Programs single device only.
• Connects to PC via high speed parallel interface.
• Includes a high speed CPU and expandable to 128M memory
buffer.
• Compact SMT design weights only 4.4 lb.
• Free online software updates and support.
• INCLUDES: Programmer with 40 pin ZIF socket, interface
cable, software, user manual and power supply.
MODEL ALL-11P3
SYSTEM REQUIREMENTS (BOTH ALL-11P3 AND ALL-11C2):
486/Pentium or compatible with minimum 32MB extended
memory. 5 MB minimum free hard disk space. Windows 95/98/
NT/2000/XP.
MODEL ALL-11C2
WINDOWS VERSION
YES Key
Allows One Key
Operation For
Mass Production
BUSY LED
Indicates
Programmer
Operation Is
GOOD LED
LED ON indicates
An Operation Was
Performed OK
40 PIN ZIF SOCKET
• All features as in Model ALL-11C2.
• Consists of universal base and exchangeable pack option:
— 40 pin ZIF socket (included)
— Optional gang programmer available
• High speed parallel port and USB connects the programmer
to any desktop to laptop PC running Windows 95/98/NT/2000/
XP.
SUPPORTS OVER 12,000 DEVICES
