This Development Board provides a complete, low cost multimedia platform featuring Altera Cyclone (EP1C6Q248C8) FPGA device. With the built-in USB blaster circuits, this
TR1 development board has many multimedia features for users to develop advanced video, audio, memory and storage applications using the most popular components in
consumer electronic products such as DVD and VCD players. Also includes a C++ program and controller IPs for peripheral controls to allow users to build up advanced ap-
plications in shortest timeframe. Users can use either the USB blaster link or RS-232 link to control the board.
FPGA DEVELOPMENT BOARD W/BUILT IN USB PORT
Part No. 01FPGA1 • Price: $159.00
Altera Cyclone 1C6
240-pin TQFP
8 User LEDs
Power ON/
OFF Switch
50Mhz OSC
9V DC Power
Supply
Connector
8 Push-button
Switches
8MByte
SDRAM
1MByte Flash Memory
(under the CF card)
Expansion Headers
(with Protection
Resistors)
USB
Port
VGA
Out
TV
Out
PS2
Port
RS232
Port
4-Digit 7-Seg. Display
FPGA development board
• Altera EP1C6Q240C8
• Altera EP1S Serial Configu-
ration Device
• Built-in USB Blaster pro-
gramming circuitry.
• Support both JTAG and AS
mode programming
• Option to power via univer-
sal serial bus (USB)
• Eight LEDs
• Eight Schmitt-trigger de-
bounced push buttons
• 1MByte Flash Memory
• 8MByte SDRAM (1M x 4 x
16)
• CF Card Socket (True IDE
mode)
• 16-bit CD-quality Audio
DAC with line-out connector
• TV Encoder with TV Out
jack
• RS-232 Transceiver with
9-pin connector
• VGA DAC (4-bit resistor
network) with VGA-out
connector
• PS2 Keyboard/mouse
connector
• 4-bit DIP switches
• 4-bit 7-SEG display
module
• Two-40 pin expansion
slots.
Cables and accessories
• USB A->B cable (for
both USB-blaster
programming and the
TREX C1 API controll)
• 7.5V DC Power Supply
• Quartus ® II Web Edition
design software
Reference designs and
C++ applications
• Lab manual for using
the C++
• Lab Manuals for using
the reference designs
TRAINERS / SOFTWARE
T-REX C1 DEVELOPMENT KIT
FPGA BOARD WITH USB PORT
• Provides means of learning
and prototyping digital logic, computer systems
and FPGA code. This board provides a com-
plete low cost platform using Altera Cyclone
II (EP2C8) chip connected to various LEDs,
switches and 7-segment displays. One can use
web edition of Altera Quartus II to design FPGA
code using Verilog HDL, VHDL as well as other
design methods
• USB port for transferring FPGA to chip configura-
tions
• 8 red LEDs, 8 green LEDs
• 2 sets of 4 SPDT switches
• 2 debounced, 4 non-debounced switches
• 40 pin and 2 DB-9 I/O connectors for interfacing
• 24MHz clock; can be multiplied or divided using
interal PLL
Part No. 01FPGA4 • Price: $149.00 Part No. 01FPGA2 • Price: $170.00
FPGA ALTERA BOARD WITH USB
Provides ideal vehicle for advanced design proto-
typing in the multimedia, storage, and networking.
The board offers a rich set of features that make
it suitable for use in a laboratory environment for
university and college courses, for a variety of
design projects, as well as for the development of
sophisticated digital systems. Altera provides a suite
of supporting materials for the DE1 board, including
tutorials, "ready-to-teach" laboratory exercises, and
illustrative demonstrations.
Altera DE1: Available on the Altera website (http://
university.altera.com/materials/unv-dev-edu-boards.html)
FEATURES
DE1 board provides users many features to enable
various multimedia project development. Component
selection was made according to the most popular design in volume production mul-
timedia products. The DE1 platform allows users to quickly understand all the insight
tricks to design projects for industry.
• Altera Cyclone II 2C20 FPGA with 20000
LEs
• Altera Serial Configuration deivices
(EPCS4) for Cyclone II 2C20
• USB Blaster built in on board for pro-
gramming and user API controlling
• JTAG Mode and AS Mode are supported
• 8Mbyte (1M x 4 x 16) SDRAM
• 4Mbyte Flash Memory
• 512Kbyte(256Kx16) SRAM
• SD Card Socket
• 4 Push-button switches
• 10 DPDT switches
• 8 Green User LEDs
• 10 Red User LEDs
• 4 Seven-segment LED displays
• 50MHz oscillator ,24MHz oscillator
,27MHz oscillator and external clock
sources
• 24-bit CD-Quality Audio CODEC with line-
in, line-out, and microphone-in jacks
• VGA DAC (4-bit R-2R per channel) with
VGA out connector
• RS-232 Transceiver and 9-pin connector
• PS/2 mouse/keyboard connector
• Two 40-pin Expansion Headers
• DE1 Lab CD-ROM which contains
many examples with source code
