TRAINERS
WHY USE OLD, OBSOLETE TTL GATES TO IMPLEMENT
COMPLEX LOGIC & STATE MACHINE DESIGNS?
PLDT-3 PROGRAMMABLE
LOGIC DEVICE PROTOTYPING BOARDS
User design software available from the chip manufac-
turer.* Then down-load your design from the PC with the
parallel port cable (included). EACH comes with a user’s
manual containing a complete description of the board
together with Lab experiments, power supply and cable.
$ 79 00
ONLY
with the XILINX® XC95108™ CPLD
Part No. Description Price
01PLDT3 PLDT-3 Board $79.00
31DELE Digital Electronics Laboratory Experiments 56.50
32RSRFPGAACC Accessory Kit 19.9 5
* Design software is available at the following chip manufacturer website: For the
Xilinx chip: http://www.xilinx.com
You can also go to the PLDT page on the Electronix Express website at http;/
/www.elexp.com/tst_pldt3.htm which has links directly to the software pages.
DIGITAL ELECTRONICS LABORATORY EXPERIMENTS
USING THE XILINX® XC95108™ CPLD WITH XILINX®
FOUNDATION DESIGN AND SIMULATION SOFTWARE
This digital laboratory manual by James Stewart and Chao-
Ying Wang, published by Prentice Hall, allows introductory
digital electronics students to use the Xilinx® software early
in the course. Features of this manual include:
• A step-by-step introduction to Xilinx ® software.
• Class-tested laboratory experiments guaranteed to work.
• More than one experiment for most typical areas to allow for
greater flexibility in the laboratory environment.
HAS THE ON-BOARD I/O CAPABILITY YOU NEED:
• DIP Switches
• De-bounced Momentary
Switches
• LEDs
Power Supply and
Cable Included
ACCESSORY KIT (32RSRFPGAACC)
INCLUDES: 1 RSR MB-102 Breadboard with Wire Kit
1 RSR LP-610 Logic Probe
50 Breadboarding Pins
• 7-Segment Displays
• Numerous Connectors for
Jumper-Wires and Ribbon
Cables
WHY USE OLD, OBSOLETE TTL GATES TO IMPLEMENT
COMPLEX LOGIC & STATE MACHINE DESIGNS?
PLDT-2 PROGRAMMABLE
LOGIC DEVICE PROTOTYPING BOARDS
with the ALTERA ® EPM7128SLC™ CPLD
HAS THE ON-BOARD I/O CAPABILITY YOU NEED:
• DIP Switches
• De-bounced Momentary Switches
• LEDs
User design software available from the chip manufacturer.* Then down-
load your design from the PC with the parallel port cable (included). each
comes with a user’s manual containing a complete description of the
board together with Lab experiments, power supply and cable.
Breadboard Optional
Part No. Description Price
01PLDT2 PLDT-2 Board $79.00
31CPLD CPLD Programming Lab Manual 58.00
31P0130453056 Experiments In Digital 60.75
Fundamentals With VHDL
311401840302 Digital Design With CPLD 140.80
Applications & VHDL, 2Ed.
32RSRFPGAACC Accessory Kit 19.95
* Design software is available at the following chip manufacturer websites:
For the Altera chip: http://www.altera.com. You can also go to the PLDT
page on the Electronix Express website at http://www.elexp.com/tst_pldt.htm
which has links directly to the software pages.
CPLD PROGRAMMING & DIGITAL
LOGIC SIMULATION –
By Steve Waterman
A lab manual to accompany any digital electronics textbook. This lab
manual can help you learn how to use Max + plusII software by Altera
Corporation. This manual starts with fundamentals of logic gates, then
progresses to MSI devices, latches and flip flops. Then it moves on to clock depen-
dent circuits including counters and registers, memory addressing, and converters.
ACCESSORY KIT (32RSRFPGAACC)
INCLUDES: 1 RSR MB-102 Breadboard with Wire Kit
1 RSR LP-610 Logic Probe
50 Breadboarding Pins
Provides laboratory exercises that support Digital Fundamentals
with VHDL by Tom Floyd. The manual supports the PLDT-2 and
PLDT-3 boards from RSR Electronics, as well as the DeVry Uni-
versity board, and the Altera University Program board.
• 7-Segment Displays
• Numerous Connectors for
Jumper-Wires and Ribbon Cables
$ 79 00
ONLY
Power Supply and
Cable Included
DIGITAL DESIGN WITH CPLD
APPLICATIONS & VHDL, 2ED
2nd edition; 896 pages. Updated Altera’s Quartus II software and
Lab.Source CD included with book. Thorough coverage of basic
techniques and fundamentals to advanced principles.
