Chapter 3 Status Screens
P-2304R-P1 Series User’s Guide
46
3.4 VoIP Statistics
To access this screen, open the Status screen (see Section 3.1 on page 41 ), and click (Details
...) next to VoIP Statistics.
Figure 12 VoIP Statistics
Each field is described in the following table.
Table 7 VoIP Statistics
LABEL DESCRIPTION
SIP Status
Account This column displays each SIP account in the ZyXEL Device.
Registration This field displays the current registration status of the SIP account. You can
change this in the Status screen.
Registered - The SIP account is registered with a SIP server.
Register Fail - The last time the ZyXEL Device tried to register the SIP account
with the SIP server, the attempt failed. The ZyXEL Device automatically tries to
register the SIP account when you turn on the ZyXEL Device or when you activate
it.
Inactive - The SIP account is not active. You can activate it in VoIP > SIP > SIP
Settings.
Last Registration This field displays the last time you successfully registered the SIP account. It
displays N/A if you never successfully registered this account.
URI This field displays the account number and service domain of the SIP account.
You can change these in VoIP > SIP > SIP Settings.
Protocol This field displays the transport protocol the SIP account is currently using.
Message Waiting This field indicates whether or not there are any messages waiting for the SIP
account.
Last Incoming
Number
This field displays the last number that called the SIP account. It displays N/A if no
number has ever dialed the SIP account.
Last Outgoing
Number
This field displays the last number the SIP account called. It displays N/A if the
SIP account has never dialed a number.
