Xerox Document Centre ColorSeries 50 LP/ST Novell NetWare ® Quick Install
Step 1 Set Up the Printer
1.
Run NWADMIN, NWADMIN32 or PCONSOLE
to set up a printer and queue objects. Refer to
the Novell documentation, if needed.
2.
Press the Administration button, located on
the printer Control Panel.
3.
Press Tools on the Touch Screen.
4.
Using the keypad, enter your Access Number
and then press Enter on the Touch Screen.
The default Access Number is 11111. It may
have been changed by a System Administrator.
5.
Press Machine Setup on the Touch Screen.
The list of available Items and their current
settings are displayed.
6.
Press IP Address in the Items list, or use the
scroll buttons to locate the IP Address field.
7.
Press Change Settings on the Touch Screen.
8.
After entering the IP Address using the keypad,
press Save.
9.
Press Frame Type, located in the Items list, or
use the scroll buttons to locate the Frame
Type.
10.
Press Change Settings on the Touch Screen.
11.
After pressing the desired button for Frame
Type, press Save.
12.
If you are using Token Ring, also set the
Source Routing value.
13.
Press Close repeatedly until you exit the
Administration screens.
14.
Power off and power on the printer. Allow at
least 30 seconds between powering off and
powering on the printer. A Configuration Report
will print in approximately 5 minutes. The
information on the Configuration Report can be
very helpful in completing the network
installation and troubleshooting problems with
your printer.
15.
Continue with Step 2 Customize Printer
Connectivity Settings .
Before You Start:
• For all NetWare environments, record the
following information, making sure to capture
case-sensitive information:
a) Frame Type
b) Print Server Name
c) assigned Print Server Password
(optional)
d) NDS Tree and NDS Context Name (for
NDS only).
• When using Novell NetWare version 3.x, you
must have a Queue and Print Server created for
the server, and know the Frame Type being used.
• When using Novell NetWare 4.x or 5.x for a
Bindery installation, you must create the Queue
and Print Server as Bindery objects, and know
the context in which they are created. For a
Bindery installation, you must also record the
File Server Name.
• When using Novell NetWare 4.x or 5.x for an
NDS installation, you must create the Printer,
Print Server and Queue, and know the Context
and Tree Name in which they are created.
• Decide now if you will use CentreWare Internet
Services or CentreWare Printer Admin Services
to customize printer connectivity settings.
For assistance, contact your local Xerox Customer Support Center: USA: 1-800-821-2797 Canada: 1-800-939-3769
Bustled Controller, Part Numbers 97N00893 and 97N00894 are for use with Xerox Corp. Digital Color Product Model YFA-1.
