Extensions for Steinberg DAW Owner’s Manual 3
For MOTIF XS
For MOTIF-RACK XS
■
Auto settings of Remote Device
With Extensions for Steinberg DAW installed, the MOTIF XS
connected to a computer via an IEEE1394 cable will be regis-
tered as the Remote Device of Cubase. Also, the detailed settings
such as MIDI Ports will be set automatically. You can confirm
these points by selecting [Devices]
→
[Device Setup] to call up
the Device Setup dialog box.
For details about function assignments, refer to the Owner's
Manual and Data List 2 of the MOTIF XS.
The MOTIF-RACK XS cannot be set as a Remote Device.
The Remote Device name shown in Cubase and the MIDI Port
name are as follows:
Remote Device name : Yamaha MOTIF XS
MIDI In and Out Port name : MOTIF XS Remote
NOTE
• Even if the MIDI Port is changed, it will be reset to the above one
when Cubase is restarted.
• The Remote Control function is available also when the MOTIF XS
is connected to a computer via a USB cable. In this case, click [+]
from the Device Setup window to call up the Device List, and then
select “Yamaha MOTIF XS.” You will also need to set the MIDI
Ports manually in this case.
MIDI port
number of
MOTIF XS
IN (Computer ←
MOTIF XS)
OUT (Computer →
MOTIF XS)
1 MOTIF XS MOTIF XS
2 MOTIF XS Remote MOTIF XS Remote
3 MOTIF XS MIDI IN MOTIF XS MIDI OUT
Audio port
number of
MOTIF XS
IN (Computer ←
MOTIF XS)
OUT (Computer →
MOTIF XS)
1 MOTIF XS Main L MOTIF XS Main L
2 MOTIF XS Main R MOTIF XS Main R
3 MOTIF XS 1 MOTIF XS mLAN L
4 MOTIF XS 2 MOTIF XS mLAN R
5 MOTIF XS 3 MOTIF XS Asgn L
6 MOTIF XS 4 MOTIF XS Asgn R
7 MOTIF XS 5 —
8 MOTIF XS 6 —
9 MOTIF XS 7 —
10 MOTIF XS 8 —
11 MOTIF XS 9 —
12 MOTIF XS 10 —
13 MOTIF XS 11 —
14 MOTIF XS 12 —
15 MOTIF XS 13 —
16 MOTIF XS 14 —
MIDI port
number of
MOTIF-
RACK XS
IN (Computer ←
MOTIF-RACK XS)
OUT (Computer →
MOTIF-RACK XS)
1 MOTIF-RACK XS MOTIF-RACK XS
2 — —
3
MOTIF-RACK XS
MIDI IN MOTIF-RACK XS
MIDI OUT
Audio port
number of
MOTIF-
RACK XS
IN (Computer ←
MOTIF-RACK XS)
OUT (Computer →
MOTIF-RACK XS)
1
MOTIF-RACK XS
Main L MOTIF-RACK XS
Main L
2
MOTIF-RACK XS
Main R MOTIF-RACK XS
Main R
3 MOTIF-RACK XS 1
MOTIF-RACK XS
mLAN L
4 MOTIF-RACK XS 2
MOTIF-RACK XS
mLAN R
5 MOTIF-RACK XS 3
MOTIF-RACK XS
Asgn L
6 MOTIF-RACK XS 4
MOTIF-RACK XS
Asgn R
7 MOTIF-RACK XS 5 —
8 MOTIF-RACK XS 6 —
9 MOTIF-RACK XS 7 —
10 MOTIF-RACK XS 8 —
11 MOTIF-RACK XS 9 —
12 MOTIF-RACK XS 10 —
13 MOTIF-RACK XS 11 —
14 MOTIF-RACK XS 12 —
15 MOTIF-RACK XS 13 —
16 MOTIF-RACK XS 14 —
Audio port
number of
MOTIF-
RACK XS
IN (Computer ←
MOTIF-RACK XS)
OUT (Computer →
MOTIF-RACK XS)
