Loading paper....
1
Pull open the paper
cassette and push down
on the pressure plate until
it locks into position.
2 Adjust the rear paper guide
to the required paper
length.
To load a different size
paper, lift and insert the
rear guide into the
corresponding position.
Fan the paper and insert
into the cassette.
LGL
FOLIO
A4
LT R
Rear Guide
3
NOTE: Ensure the paper
corners are under the snubbers
and do not fill above the max fill
line.
While squeezing the side
guide, move it toward the
stack of paper until it
gently touches the stack
and then close the paper
cassette.
Max Fill Line
Snubbers
Side Guide
