14 of 22 Revision Nov 2008
Grammage
Weight (gsm)
The Xerox Guaranteed Media List contains Xerox paper and specialty media that has been extensively tested on the Xerox iGen3 90/100/110 Digital Production Press for image quality and performance. All Xerox paper and specialty media on this list are digitally optimized, designed
and manufactured for optimal performance in Xerox digital printing equipment. Our extensive testing and stringent specifications ensure that we are able to guarantee the performance and consistency of Xerox paper and specialty media. Xerox paper and specialty media are tested
and qualified by Xerox laboratories to guarantee consistent quality.
iGen3 Digital Production Press Guaranteed Media List - Europe - April 2010
Best Practices for Operation
Weight of the
paper in grams
per square meter
Sides Coated Coating Type Type Sequence Color
Thickness
(microns)
Cleanup Finish Other Size
Stock Library Name (Full Media Name)
It is imperative to utilize the bolded, abbreviated stock name for
easy migration to future enhancements to the stock library and
media management tools.
Standard cut sizes
Drilled A4 A3 SRA3
XeroxDocuGlossC 1up
(Xerox DocuGloss Card 1up)
003R97678 163 Uncoated N/A Plain 0 White 170 No Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in the
latest Customer Maintenance Manual Section 3.
Stack quality and stack height may be affected due to media structure or high area coverage.
For uniform image quality do not image within 5 mm of card edge.
Load and stack 50-100 sheets maximum due to media structure.
TAB may need to be cleaned prior to running media.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
For feeding without a DocuCard Enabler Kit feed tray load max is 50-100 sheets.
XeroxDC BusCards
(Xerox Digital Color Special Advanced Media Business Cards)
003R97512 195 Uncoated N/A Plain 0 White 226 No Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in the
latest Customer Maintenance Manual Section 3.
For uniform image quality, do not image within 3 mm of card edges (side 1) or within 7 mm of tape edges (side 2).
Stack quality and stack height may be affected due to media structure or high area coverage.
XeroxDocuMag C
(Xerox DocuMagnet Coated)
003R96071 280
C1S (Coated
One Side)
Gloss Plain 0 White 194 No Smooth
Simplex only recommended
For uniform image quality do not image within 5 mm of card edge.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
XeroxDocuMag U
(Xerox DocuMagnet Uncoated)
003R96072 280
C1S (Coated
One Side)
Matte Plain 0 White 170 No Regular
If Transfer set point adjustments are required for snow defects, refer to the Snow Sample Artifact Procedure in the
latest Customer Maintenance Manual Section 3.
Simplex only recommended
For uniform image quality do not image within 5 mm of card edge.
A DocuCard Enabler Kit is available to facilitate feeding and stacking of greater volumes.
Specialties- Synthetic Films
XeroxPremiumNeverTear95
(Xerox Premium NeverTear 95 micron)
No 003R98056 003R98057 003R98031 003R98032 125
Coated Two
Sides
Gloss Plain 0 White 95 Yes Smooth Static build up may affect media runnability and/or stacking.
XeroxPremiumNeverTear120
(Xerox Premium Never Tear 120 micron)
No 003R98058 003R98059 003R98035 003R98036 155
Coated Two
Sides
Gloss Plain 0 White 120 Yes Smooth Static build up may affect media runnability and/or stacking.
XeroxDuraPaper X250
(Xerox DuraPapaer X250)
003R97513 200 Uncoated N/A Plain 0 White 255 No Regular
If image permanence adjustment is required, refer to ADJ 1-Pressure Roll Contact Arc Adjustment procedure in the
latest Customer Maintenance Manual.
Specialties- Other
Xerox UltraMagnet
(Xerox Ultra Magnet)
003R98060 350 Coated One Side Gloss Plain White 194 No Smooth
Simplex only recommended
It is recommended that this media be run to stacker top tray.
Static build up may affect media runnability and/or stacking.
Feed from a lower tray only.
To enable running toggle NVM 12509 (Lower Tray Multifeed Detected FLTByp).
To enable running Service must set NVM 6876 (LE Late tat TAR sensor Jam Offset) to maximum value.
Output to top tray or bypass tray, if enabled.
Lead edge to Trail edge skew.
For best print quality print 15 mm from edges of the sheet.
XeroxTransferPaper
(Xerox One Step Transfer Paper)
003R97949 003R97951 118 Coated One Side Gloss Custom 0 White 143 No Smooth
Simplex only recommended
Static build up may affect media runnability and/or stacking.
XeroxLasWinGraphiX C
(Xerox Laser Window GraphiX Clear)
003R97494 003R98675 003R98676 003R98677 200 Coated One Side Gloss Transparency Clear 114 No Smooth
For uniform image quality, do not image within 3 mm of die cut on back of decal.
Simplex only recommended
Static build up may affect media runnability and/or stacking.
XeroxLasWinGraphiX O
(Xerox Laser Window GraphiX Opaque)
003R97511 003R97539 003R98678 003R98679 200 Coated One Side Gloss Transparency Clear 114 No Smooth
For uniform image quality, do not image within 3 mm of die cut on back of decal.
Simplex only recommended
Static build up may affect media runnability and/or stacking.
