14
1.Clean the condenser when
light Condenser comes on.
The condenser is situated at
the lower part of the cabinet
behind a small door. To open
the door, push the catch as
per picture.
During the drying cycle or at the
end, it is normal for water to be
present on the surface of the
condenser insertion.
2. To pull out the condenser,
first turn the two red stops
downwards.
3. Then remove the con-
denser unit holding it at the
handle.
Cleaning the condenser unit
4. Clean the rubber seal round
the condenser cabinet and in
the inner part of the small door
with a damp cloth.
Important:
Do not use pointed
objects or utensils to
clean the spaces between
the plates, as this could
damage the condenser
and make it permeable.
Re-fit the condenser, turn
the red stops upwards and
close the door.
Important:
Do not use this appliance
if the condenser has not
been fitted.
Emptying the water reservoir
Important:
Water extracted from the laundry condenses inside the machine and is collected in a
reservoir.
The reservoir must be emptied after each drying cycle to ensure efficient operation when
the machine is next used. The pilot light Empty Tank reminds you of this operation.
Proceed as follows:
