Xerox B1 User Manual
Page 10
JAM DETECTION
The display represents the top tray and the paper path area. When part of the mimic is
illuminated, there is a problem in this area.
Operator Manual
Page 9 - 10
Initial issue: 02/03
Latest revision: 10/03
Top tray
This window is
blinking when the
machine does a
set-up, and ligh-
ted when the
machine is ready.
If the top tray area is illuminated, you have to open the top cover to
check the area and clear the problem.
If the paper path area is illuminated, you have to open the top cover to
check the area and clear the problem.
Paper path
