CVP-109/107/105/103/700
34
○
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
SYMPHONIC (chorus, variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1
2 LFO Depth 0–127 0–127
3 Delay Offset 0.0mS–50mS 0–127 table#2
4
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10 Dry/Wet D63>W – D=W – D 1–127 ●
11 EQ Mid Frequency 100Hz–10.0kHz (variation block) 14–54 table#3 CVP-109/107/700 only
12 EQ Mid Gain -12–+12dB (variation block) 52–76 CVP-109/107/700 only
13 EQ Mid Width 1.0–12.0 (variation block) 10–120 CVP-109/107/700 only
14
15
16
ENSEMBLE DETUNE (chorus, variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 Detune -50–+50cent 14–114
2 Lch Init Delay 0.0mS–50mS 0–127 table#2
3 Rch Init Delay 0.0mS–50mS 0–127 table#2
4
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1–127 ●
11 EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700 only
(variation, insertion block)
12 EQ Low Gain -12–+12dB 52–76 CVP-109/107/700 only
(variation, insertion block)
13 EQ High Frequency 500Hz–16.0kHz 28–58 table#3 CVP-109/107/700 only
(variation, insertion block)
14 EQ High Gain -12–+12dB 52–76 CVP-109/107/700 only
(variation, insertion block)
15
16
AMBIENCE (variation block)
No. Parameter Display Value See Table Comment Control
1 Delay Time 0.0mS–50mS 0–127 table#2
2 Output Phase normal/invers 0–1
3
4
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10 Dry/Wet D63>W – D=W – D 1–127 ●
11
12
13
14
15
16
ROTARY SPEAKER (variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1 ●
2 LFO Depth 0–127 0–127
3
4
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10 Dry/Wet D63>W – D=W – D 1–127
11 EQ Mid Frequency 100Hz–10.0kHz (variation block) 14–54 table#3 CVP-109/107/700 only
12 EQ Mid Gain -12–+12dB (variation block) 52–76 CVP-109/107/700 only
13 EQ Mid Width 1.0–12.0 (variation block) 10–120 CVP-109/107/700 only
14
15
16
2WAY ROTARY SPEAKER (variation block)
No. Parameter Display Value See Table Comment Control
1 Rotor Speed 0.0Hz–39.7Hz 0–127 table#1 ●
2 Drive Low 0–127 0–127
3 Drive High 0–127 0–127
4 Low/High L63>H – L=H – L 1–127
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10
11 Crossover Frequency 100Hz–10.0kHz 14–54 table#3
12 Mic L-R Angle 0deg–180deg(resolution=3deg.) 0–60
13
14
15
16
TREMOLO (variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1 ●
2 AM Depth 0–127 0–127
3 PM Depth 0–127 0–127
4
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10
11 EQ Mid Frequency 100Hz–10.0kHz (variation block) 14–54 table#3 CVP-109/107/700 only
12 EQ Mid Gain -12–+12dB (variation block) 52–76 CVP-109/107/700 only
13 EQ Mid Width 1.0–12.0 (variation block) 10–120 CVP-109/107/700 only
14 LFO Phase Difference -180–+180deg(resolution=3deg.) 4–124
15 Input Mode mono/stereo 0–1
16
AUTO PAN (variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1 ●
2 L/R Depth 0–127 0–127
3 F/R Depth 0–127 0–127
4 PAN Direction L<->R,L->R,L<-R,Lturn,Rturn,L/R 0–5
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10
11 EQ Mid Frequency 100Hz–10.0kHz (variation block) 14–54 table#3 CVP-109/107/700 only
12 EQ Mid Gain -12–+12dB (variation block) 52–76 CVP-109/107/700 only
13 EQ Mid Width 1.0–12.0 (variation block) 10–120 CVP-109/107/700 only
14
15
16
PHASER 1 (chorus, variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1
2 LFO Depth 0–127 0–127
3 Phase Shift Offset 0–127 0–127
4 Feedback Level -63–+63 1–127
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10 Dry/Wet D63>W – D=W – D 1–127 ●
11 Stage 4,5,6 (chorus, insertion block) 4–6 CVP-109/107/700 only
4–12 (variation block) 4–12 CVP-109/107/700
6–10 (variation block) 6–10 CVP-105/103
12 Diffusion mono/stereo 0–1
13
14
15
16
PHASER 2 (variation block)
No. Parameter Display Value See Table Comment Control
1 LFO Frequency 0.00Hz–39.7Hz 0–127 table#1
2 LFO Depth 0–127 0–127
3 Phase Shift Offset 0–127 0–127
4 Feedback Level -63–+63 1–127
5
6
EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
7 EQ Low Gain -12–+12dB 52–76
8 EQ High Frequency 500Hz–16.0kHz 28–58 table#3
9 EQ High Gain -12–+12dB 52–76
10 Dry/Wet D63>W – D=W – D 1–127 ●
11 Stage 3,4,5,6 3–6 CVP-109/107/700
12 3,4,5 3–5 CVP-105/103
13 LFO Phase Difference -180deg–+180deg 4–124
(resolution=3deg.)
14
15
16
DISTORTION
OVERDRIVE (variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 Drive 0–127 0–127 ●
2 EQ Low Frequency 32Hz–2.0kHz 4–40 table#3 CVP-109/107/700
50Hz–2.0kHz 8–40 table#3 CVP-105/103
3 EQ Low Gain -12–+12dB 52–76
4 LPF Cutoff 1.0k–Thru 34–60 table#3
5 Output Level 0–127 0–127
6
7
EQ Mid Frequency 100Hz–10.0kHz 14–54 table#3 CVP-109/107/700
500Hz–10.0kHz 28–54 table#3 CVP-105/103
8 EQ Mid Gain -12–+12dB 52–76
9 EQ Mid Width 1.0–12.0 10–120
10 Dry/Wet D63>W – D=W – D 1–127
11 Edge(Clip Curve) 0–127 0–127 mild–sharp
12
13
14
15
16
COMP+DIST (variation block)
No. Parameter Display Value See Table Comment Control
1 Drive 0–127 0–127 ●
2 EQ Low Frequency 32Hz–2.0kHz 4–40 table#3
3 EQ Low Gain -12–+12dB 52–76
4 LPF Cutoff 1.0k–Thru 34–60 table#3
5 Output Level 0–127 0–127
6
7
EQ Mid Frequency 100Hz–10.0kHz 14–54 table#3
8 EQ Mid Gain -12–+12dB 52–76
9 EQ Mid Width 1.0–12.0 10–120
10 Dry/Wet D63>W – D=W – D 1–127
11 Edge(Clip Curve) 0–127 0–127 mild–sharp
12 Attack 1ms–40ms 0–19 table#8
13 Release 10ms–680ms 0–15 table#9
14 Threshold -48dB– -6dB 79–121
15 Ratio 1.0–20.0 0–7 table#10
16
AMP SIMULATOR (variation, insertion block)
No. Parameter Display Value See Table Comment Control
1 Drive 0–127 0–127 ●
2 AMP Type Off,Stack,Combo,Tube 0–3
3 LPF Cutoff 1.0k–Thru 34–60 table#3
4 Output Level 0–127 0–127
5
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1–127
11 Edge(Clip Curve) 0–127 0–127 mild–sharp
12
13
14
15
16
