Yamaha CVP-107 EU - Manual (Page 31)

CVP-109/107/105/103/700
31
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
CVP-105/103 Effect MapIf the received value does not contain an effect type in the TYPE LSB, the LSB will be directed to TYPE 0.
The panel effects are marked by “*”.REVERB TYPETYPE MSBTYPE LSBDECHEX00010203 ...07 08...16171819200000NO EFFECT0011*HALL1HALL2*HALL2*HALL3*HALL40022ROOM1ROOM2ROOM3*ROOM1*ROOM2*ROOM3*ROOM40033STAGE1STAGE2*STAGE1*STAGE20044PLATE*PLATE1*PLATE20055NO EFFECT:::015FNO EFFECT01610WHITE ROOM01711TUNNEL01812CANYON01913BASEMENT02014NO EFFECT:::1277FNO EFFECTINSERTION TYPETYPE MSBTYPE LSBDECHEX00010203 ...07 08...16171819200000THRU0011*HALL1HALL 2*HALL2*HALL3*HALL40022ROOM 1ROOM 2ROOM 3*ROOM1*ROOM2*ROOM3*ROOM40033STAGE 1STAGE 2*STAGE1*STAGE20044PLATE*PLATE1*PLATE20055DELAY L,C,R*DELAY LCR0066*DELAY LR0077*ECHO0088*CROSS DELAY0099THRU:::01913THRU02014*KARAOKE1*KARAOKE2*KARAOKE302115THRU:::0633FTHRU06440THRU06541CHORUS 1CHORUS 2*CHORUS5CHORUS 406642CELESTE 1*CHORUS4CELESTE 3*CHORUS2*CHORUS3*CHORUS1*ROTARY SP506743FLANGER 1*FLANGER4*FLANGER1*FLANGER2*FLANGER306844*SYMPHONIC2*SYMPHONIC106945ROTARY SPEAKER 1*ROTARY SP107046TREMOLO*TREMOLO1*ROTARY SP407147*AUTO PAN2*AUTO PAN1*ROTARY SP2*ROTARY SP3*TREMOLO2*GTR TREMOLO07248*PHASER07349DISTORTION0744AOVER DRIVE0754B*AMP SIMULATOR*DIST HARD*DIST SOFT0764C3BAND EQ*EQ DISCO*EQ TEL0774D2-BAND EQ0784E*AUTO WAH2*AUTO WAH10794FTHRU08050THRU08151HARMONIC ENHANCER08252*TOUCH WAH1*TOUCH WAH208353COMPRESSOR08454NOISE GATE08555THRU08656THRU08757ENSEMBLE DETUNE08858THRU:::1277FTHRU Pages: 1 … 29 30 31 32 33 … 68 wrong Brand wrong Model non readable See also other documents in the category Yamaha Synthesizers: PSR-1100 (170 pages) PSR-1100 (176 pages) PSR-290 (98 pages) YPT-310 (90 pages) CLP-230 (90 pages) CLP-230 (89 pages) YPT-300 (84 pages) DGX-205 (90 pages) MM8 EU (116 pages) MOX8 (14 pages) MOTIF XS8 (320 pages) PSR-4600 (30 pages) PSR-32 (20 pages) PSR-530 (130 pages) PSR-510 (77 pages) PSR-330 (90 pages) PSR-3500 (84 pages) PSR-500 (47 pages) PSR-41 (13 pages) PSR-4000 (165 pages) PSR-38 (55 pages) PSR-520 (102 pages) PSR-340 (128 pages) PSR-40 (16 pages) PSR-36 (28 pages) PSR-48 (45 pages) PSR-420 (73 pages) PSR-420 (75 pages) PSR-300m (39 pages) PSR-37 (30 pages) PSR-4500 (48 pages) PSR-50 (32 pages) PSR-410 (61 pages) PSR-540 (161 pages) PSR-540 (160 pages) PSR-31 (20 pages) CLP-100 (11 pages) CLP-122S (31 pages) CLP-123 (30 pages) CLP-30 (11 pages) CLP-300 (11 pages) CLP-250 (17 pages) CLP-260 (19 pages) CLP-280 (124 pages) CLP-550 (19 pages) Sitemap
If the received value does not contain an effect type in the TYPE LSB, the LSB will be directed to TYPE 0.
The panel effects are marked by “*”.
REVERB TYPE
TYPE MSB TYPE LSB
DEC HEX 00 01 02 03 ... 07 08 ... 16 17 18 19 20
000 0 NO EFFECT
001 1 *HALL1 HALL2 *HALL2 *HALL3 *HALL4
002 2 ROOM1 ROOM2 ROOM3 *ROOM1 *ROOM2 *ROOM3 *ROOM4
003 3 STAGE1 STAGE2 *STAGE1 *STAGE2
004 4 PLATE *PLATE1 *PLATE2
005 5 NO EFFECT
: : :
015 F NO EFFECT
016 10 WHITE ROOM
017 11 TUNNEL
018 12 CANYON
019 13 BASEMENT
020 14 NO EFFECT
: : :
127 7F NO EFFECT
INSERTION TYPE
TYPE MSB TYPE LSB
DEC HEX 00 01 02 03 ... 07 08 ... 16 17 18 19 20
000 0 THRU
001 1 *HALL1 HALL 2 *HALL2 *HALL3 *HALL4
002 2 ROOM 1 ROOM 2 ROOM 3 *ROOM1 *ROOM2 *ROOM3 *ROOM4
003 3 STAGE 1 STAGE 2 *STAGE1 *STAGE2
004 4 PLATE *PLATE1 *PLATE2
005 5 DELAY L,C,R *DELAY LCR
006 6 *DELAY LR
007 7 *ECHO
008 8 *CROSS DELAY
009 9 THRU
: : :
019 13 THRU
020 14 *KARAOKE1 *KARAOKE2 *KARAOKE3
021 15 THRU
: : :
063 3F THRU
064 40 THRU
065 41 CHORUS 1 CHORUS 2 *CHORUS5 CHORUS 4
066 42 CELESTE 1 *CHORUS4 CELESTE 3 *CHORUS2 *CHORUS3 *CHORUS1 *ROTARY SP5
067 43 FLANGER 1 *FLANGER4 *FLANGER1 *FLANGER2 *FLANGER3
068 44 *SYMPHONIC2 *SYMPHONIC1
069 45 ROTARY SPEAKER 1 *ROTARY SP1
070 46 TREMOLO *TREMOLO1 *ROTARY SP4
071 47 *AUTO PAN2 *AUTO PAN1 *ROTARY SP2 *ROTARY SP3 *TREMOLO2 *GTR TREMOLO
072 48 *PHASER
073 49 DISTORTION
074 4A OVER DRIVE
075 4B *AMP SIMULATOR *DIST HARD *DIST SOFT
076 4C 3BAND EQ *EQ DISCO *EQ TEL
077 4D 2-BAND EQ
078 4E *AUTO WAH2 *AUTO WAH1
079 4F THRU
080 50 THRU
081 51 HARMONIC ENHANCER
082 52 *TOUCH WAH1 *TOUCH WAH2
083 53 COMPRESSOR
084 54 NOISE GATE
085 55 THRU
086 56 THRU
087 57 ENSEMBLE DETUNE
088 58 THRU
: : :
127 7F THRU
