CVP-109/107/105/103/700
20
○ ○
MIDI Data Format / MIDI-Datenformat / Format des données MIDI / Formato de datos MIDI
(3-6-3) XG STANDARD
(3-6-3-1) XG PARAMETER CHANGE
(3-6-3-1-1) XG SYSTEM ON
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1N Device Number
01001100 4C Model ID
00000000 00 Address High
00000000 00 Address Mid
01111110 7E Address Low
00000000 00 Data
11110111 F7 End of Exclusive
Depending upon the received ON message, the SYSTEM MODE will be changed to
XG.Controllers will be reset, all values of Multi Part and Effect, and All System values
denoted by “XG” data within All System will be reset to default values in the table.
This message requires approximately 50ms to execute, so sufficient time should be allowed
before the next message is sent.
(3-6-3-1-2) XG PARMETER CHANGE
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0001nnnn 1N Device Number
01001100 4C Model ID
0aaaaaaa AA Address High
0aaaaaaa AA Address Mid
0aaaaaaa AA Address Low
0ddddddd DD Data
| |
11110111 F7 End of Exclusive
For parameters with data size of 2 or 4, transmit the appropriate number of data bytes.
For more information on Address and Parameters, refer to < Table 1-2 > (page 23) and
< Table 1-4 > ~ < Table 1-10 > (pages 23-29).
The following Parameter Changes are handled.
XG System Data
Multi Effect 1 Data
Multi EQ Data (CVP-109/107/700)
Multi Effect 2 Data (CVP-109/107/700)
Special Effect Data (CVP-109/107/700)
Multi Part Data
A/D Part Data (CVP-109/107/700)
Drums Setup Data
(3-6-3-2) XG BULK DUMP
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0000nnnn 0N Device Number
01001100 4C Model ID
0bbbbbbb BB ByteCount
0bbbbbbb BB ByteCount
0aaaaaaa AA Address High
0aaaaaaa AA Address Mid
0aaaaaaa AA Address Low
0ddddddd DD Data
| |
0ccccccc CC Check sum
11110111 F7 End of Exclusive
For more information on Address and Byte Count, refer to < Table 1-2 > ~ < Table 1-10 >
(pages 23-29).
The Check Sum value is set such that the sum of Byte Count, Address, Data, and Check Sum
has value zero in its seven least significant bits.
If the top of the block is appointed to the Address the XG Bulk Dump, Bulk Request will be
received.
The Block is a unit that consists of the data, arranged in the list, as the Total Size.
The following Bulk Dumps are handled.
XG System Data
Multi Effect 1 Data(Individual effect unit)
Multi EQ Data (CVP-109/107/700)
Multi Effect 2 Data (CVP-109/107/700)
Special Effect Data (CVP-109/107/700)
Multi Part Data(Individual part unit)
A/D Part Data (CVP-109/107/700)
Drums Setup Data(Individual note unit)
System Information(Transmit only)
(3-6-3-3) XG PARAMETER REQUEST (Receive only)
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0011nnnn 3n Device Number
01001100 4C Model ID
0aaaaaaa AA Address High
0aaaaaaa AA Address Mid
0aaaaaaa AA Address Low
11110111 F7 End of Exclusive
For more information on Address and Byte Count refer to < Table 1-2 > (page 23) and
< Table 1-4 > ~ < Table 1-10 > (pages 23-29).
The following Parameter Requests are handled.
XG System Data
Multi Effect 1 Data
Multi EQ Data (CVP-109/107/700)
Multi Effect 2 Data (CVP-109/107/700)
Special Effect Data (CVP-109/107/700)
Multi Part Data
A/D Part Data (CVP-109/107/700)
Drums Setup Data
(3-6-3-4) XG DUMP REQUEST (Receive only)
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
0010nnnn 2n Device Number
01001100 4C Model ID
0aaaaaaa AA Address High
0aaaaaaa AA Address Mid
0aaaaaaa AA Address Low
11110111 F7 End of Exclusive
For more information on Address and Byte Count refer to < Table 1-2 > ~ < Table 1-10 >
(pages 23-29).
The following Dump Requests are handled.
XG System Data
Multi Effect 1 Data(Individual module unit)
Multi EQ Data (CVP-109/107/700)
Multi Effect 2 Data (CVP-109/107/700)
Special Effect Data (CVP-109/107/700)
Multi Part Data(Individual part unit)
A/D Part Data (CVP-109/107/700)
Drums Setup Data(Individual note unit)
System Information
(3-6-4) CLAVINOVA MIDI COMPLIANCE
(3-6-4-1) INTERNAL CLOCK / EXTERNAL CLOCK (Receive only)
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA ID
01110011 73 Clavinova ID
00000001 01 Clavinova common ID
0000001n 0N N: 2(Internal Clock),3(External Clock)
11110111 F7 End of Exclusive
(3-6-4-2) BULK DUMP ORGAN FLUTE DATA (CVP-109/107/700)
binary hexadecimal
11110000 F0 Exclusive status
01000011 43 YAMAHA
01110011 73 CLAVINOVA ID
00000001 01 Model ID (Clavinova common ID)
00000110 06 Bulk ID
00001011 0B Bulk No.(ORGAN FLUTE Bulk Dump DATA)
0000nnnn 0n Data Length
0000nnnn 0n Data Length
0000nnnn 0n Data Length
0000nnnn 0n Data Length (Data Length=nnnnH bytes)
0ddddddd dd1 Bulk Data
: :
0ccccccc cc don’t care
11110111 F7 End of Exclusive
