Xerox 5760/5765 (MajestiK Color Series) Digital Color Copier / Printer
Space Requirements
Space Requirements
Configurations
Moveabl
e
Width (inches)
Standalone
w/Fiery
Depth
(Inches)
Standalone
or w/Fiery
5760 w/ Catch Tray OR 5765 w/ Catch Tray OR
5760 w/ ADF w/ Catch Tray
on a floor
Yes
72”
90”
71” *
5760 w/ Catch Tray OR 5765 w/ Catch Tray OR
5760 w/ ADF w/ Catch Tray
on a mobility- plate.
Yes
72”
90”
75” *
5760 w/ Catch Tray OR 5765 w/ Catch Tray OR
5760 w/ ADF w/ Catch Tray
at a stationary install.
No
72”
90”
91” *
5760 w/ Sorter OR 5765 w/ Sorter OR
5760 w/ ADF w/ Sorter
at a stationary install.
Stationary
ONLY
88”
106”
91” *
5760 w/ ADF w/ Catch Tray & Edit Pad Option
on a floor.
Yes
103”
121”
71” *
5760 w/ ADF w/ Catch Tray & Edit Pad Option
on a mobility - plate
Yes
103”
121”
75” *
5760 w/ ADF w/ Catch Tray & Edit Pad Option
at a stationary install
No
103”
121”
91” *
5760 with ADF w/ Sorter & Edit Pad Option
at a stationary install.
Stationary
ONLY
119”
137”
91” *
Notes:
-In order to conform to US National fire codes, there must be 44” minimum clearance in front of units
installed in aisles / hallways
-Minimum floor to ceiling height requirement for all installations is 78”.
-Any configuration which includes a sorter requires a stationary install.
XEROX CUSTOMER SUPPORT CENTER - DOCUMENT #100225
