Prestige 660H and Prestige HW Series Compact Guide
7
Table 2 P660HW Front Panel LED Description
LED COLOR STATUS DESCRIPTION
On The Prestige is receiving power and
functioning properly. Green
Blinking The Prestige is rebooting.
Red On Power to the Prestige is too low.
PWR/SYS
Off The system is not ready or has
malfunctioned.
On The Prestige has a successful 10Mb Ethernet
connection. Green
Blinking The Prestige is sending/receiving data.
On The Prestige has a successful 100Mb
Ethernet connection. Amber
Blinking The Prestige is sending/receiving data.
LAN 1 to LAN 4
Off The LAN is not connected.
On The Prestige is ready, but is not
sending/receiving data through the wireless
LAN.
Blinking The Prestige is sending/receiving data
through the wireless LAN.
WLAN
(P660HW only) Green
Off The wireless LAN is not ready or has failed.
Fast
Blinking The Prestige is sending/receiving non-PPP
data.
Slow
Blinking The Prestige is initializing the DSL line.
Green
On The system is ready, but is not
sending/receiving non-PPP data.
On The connection to the PPPoE server is up. Amber
Blinking The Prestige is sending/receiving PPP data.
DSL/PPP
Off The DSL link is down.
