Prestige 660H and Prestige HW Series Compact Guide
6
Table 1 Prestige Rear Panel Description
LABEL DESCRIPTION
After you’ve made the connections, connect the power adaptor to a power supply and
push in the power button to turn on the Prestige.
The PWR/SYS LED blinks while performing system testing and then turns steady on if
the testing is successful. A LAN LED turns on if a LAN port is properly connected.
RESET You only need to use this button if you’ve forgotten the Prestige’s
password. It returns the Prestige to the factory defaults (password is
1234, LAN IP address 192.168.1.1 etc.; see your User’s Guide for
details).
2.2 Front Panel LEDs
Both front panel LEDs are the same except the P660HW has an additional WLAN LED.
Figure 2 P660HW Front Panel
Figure 3 P660HW Front Panel
Refer to the following table for more detailed LED descriptions.
