GB-2
EXZ2610DL (HE-EX)
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a
symbol concern critical points which must be taken
into consideration to prevent possible serious bodily injury, and
for this reason you are requested to read all such instructions
carefully and follow them without fail.
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in or-
der to prevent accidents, which could lead to serious bodily in-
jury or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
EXZ2610DL-PUO
HE-EX
15
16
17
2
3
4
5
6
8
9
10
11
12
13
14
1
7
18 19
1. Parts location
1 1. Loop handle
1 2. Suspension point
1 3. Stop switch
1 4. Throttle cable
1 5. Throttle trigger
1 6. Throttle set button
1 7. Shaft tube
1 8. Knob bolt
1 9. Spark arrester
10. Stater knob
11. Fuel tank
12. Primer
13. Choke lever
14. Air cleaner cover
15. Wheel
16. Blade guard
17. Blade
18. Bracket
19. J-handle
Contents
1. Parts location .................................................. 2
2. Specifications ................................................. 3
3. Warning labels on the machine ...................... 4
4. Symbols on the machine ................................ 4
5. For safe operation ........................................... 5
6. Set up ............................................................. 8
7. Fuel and chain oil ........................................... 9
8. Operation ...................................................... 10
9. Maintenance ................................................. 13
10. Storage ......................................................... 14
11. Disposal ........................................................ 14
12. Troubleshooting guide .................................. 15
