GB-10
EXZ2610DL (HE-EX)
8. Operation
WARNING
The cutting head will start rotating upon the engine
starts.
1. Feed fuel into the fuel tank and tighten the cap se-
curely.
(1)
2. Rest the unit on a flat, firm place. Keep the cutting
head off the ground and clear of surrounding objects,
as it will start rotating upon starting of the engine.
3. Push the primer several times until overflown fuel flows
out in the clear tube.
STARTING ENGINE
The ZENOAH stick edger is designed for edging lawn in
gardens, parks, roadsides and so on.
Before starting the engine, take the operating position
and adjust the handle position and the wheel height as
necessary.
ADJUSTING HANDLE POSITION
• Loosen the handle bracket screws and re-position the
handle to your best operating position. Re-tighten the
screws.
ADJUSTING WHEEL HEIGHT
• Loosen the clamp lever and change the wheel height
to obtain desired cutting depth.
(1) Deep cut (2) Shallow cut
WARNING
Never adjust wheel height with the engine running.
1
2
3
(1)
(1) Stop switch
5. Set the stop switch to the “-” position. Set the throttle
trigger to the start position (1 → 2 → 3).
Place the unit on a flat, firm place.
Keep the cutting head clear of everything around it.
6. While holding the unit firmly, pull out the starter rope
quickly until engine fires.
WARNING
The product is equipped with a centrifugal clutch
mechanism, so the cutting attachment begins to ro-
tate as soon as the engine is started by putting the
throttle into the start position. When starting the en-
gine, place the product onto the ground in a flat clear
area and hold it firmly in place so as to ensure that
neither the cutting part nor the throttle come into
contact with any obstacle when the engine starts.
4. Move the choke lever to the closed position.
(1)
(2)
(3)
(1) Choke lever (2) Close (3) Open
