13
P-871M User’s Guide
1 Select a position free of obstructions on a sturdy wall.
2 Drill two holes for the screws (M4*30). The centers of the
holes should be 120 mm apart.
"
Be careful to avoid damaging pipes or cables
located inside the wall when drilling holes for the
screws.
3 Do not screw the screws all the way into the wall. Leave a
small gap of about 0.5 cm between the heads of the
screws and the wall.
4 Make sure the screws are snugly fastened to the wall.
They need to hold the weight of the P-871M with the
connection cables.
5 Align the holes on the back of the P-871M with the screws
on the wall. Hang the P-871M on the screws.
