ENGLISH
2
1 Install Hard Drives
Note: Hard drives are NOT hot swappable. The NSA must be turned off before you
remove or install hard drive(s).
1 Pull the tab on the left of the front door of the NSA to open it.
2 Pull out the latch and
grip the sides of the
tray to remove disk tray
1. Be careful not to
break the latch. Disk
bay 1 is labelled on
your NSA (the top-left
bay).
3 Place the disk tray on a
flat surface with the
panel facing up. Place
a hard disk with the
screw holes facing up
on the same surface
and slide it into the disk
tray. Secure it with the
screws as shown.
4 Push the top of the tray
back into NSA disk bay
1 until it snaps into
place and push the
latch up as shown.
5 Repeat steps 1 to 3 for
other hard drives that
you may have.
2 Make the NSA Connections
1 Connect the Ethernet port on the rear of the NSA to a
hub, switch, or router on your network using an
Ethernet cable. Use an 8-wire Ethernet cable for
Gigabit connections.
