Yamaha QC61750 - Manual

Selecting Pickups
[Pickup Selector]
Front
Pickup
Rear
Pickup
(R)
Bridge Side → ← Neck Side
1
2 3
5
4
1 F F
2 F + C F + C
3 C C
4 C + R F + C + R
5 R F + R
Effective Pickup Coil
Pickup Selector
Position
Standard Functions
QC61750 0103
Printed in Japan
(F) (C)
Output Jack
Master Volume Control
5 Way Selector Switch
Front Pickup
Rear Pickup
Master Tone Control
With Push/Push Switch
Center Pickup
Center
Pickup
Down Up
Tone Control
Knob
position
Includes front pickup to-
gether with standard
position 4 & 5.
