ZyXEL G-202 User’s Guide
Chapter 5 Access Point Mode Configuration 63
5.3 The Configuration Screen
Click Configuration in the ZyXEL utility screen to display the screen as shown.
Figure 40 Access Point Mode: Configuration
Current Channel This field displays the radio channel the G-202 is currently using.
Transmission Rate This field displays the current transmission rate of the G-202 in megabits per
second (Mbps).
Security This field shows whether data encryption is activated (WEP) or inactive
(DISABLE).
MAC This field displays the MAC address of the G-202.
Output Power This field shows the strength of the G-202’s antenna gain or transmission power.
Association List This table lists up to 16 wireless clients that are currently connected to the G-202.
denotes a wireless client without WEP security.
denotes a wireless client with WEP security enabled.
MAC Address This field displays the MAC addresses of a wireless client that is currently
connected to the G-202.
Refresh Click Refresh to update this screen.
Table 16 Access Point Mode: Link Info (continued)
LABEL DESCRIPTION
