ZyXEL G-202 User’s Guide
42 Chapter 4 Wireless Station Mode Configuration
4.2 The Link Info Screen
When the ZyXEL utility starts, the Link Info screen displays, showing the current
configuration and connection status of your G-202.
Figure 22 Station Mode: Link Info
The following table describes the labels in this screen.
Table 3 Station Mode: Link Info
LABEL DESCRIPTION
AP Mode
Station Mode Use the check box to set the G-202 to operate in wireless station or access point
mode. Refer to Section 1.2.3 on page 21 for more information.
Wireless Network
Status
Profile Name This is the name of the profile you are currently using.
Network Name
(SSID)
The SSID identifies the wireless network to which a wireless station is associated.
This field displays the name of the wireless device to which the G-202 is
associated.
AP MAC Address This field displays the MAC address of the AP or peer computer to which the G-202
is associated.
Network Type This field displays the network type (Infrastructure or Ad-Hoc) of the wireless
network.
Transmission Rate This field displays the current transmission rate of the G-202 in megabits per
second (Mbps).
Security This field displays whether data encryption is activated (WEP (WEP or 802.1x),
TKIP (WPA/WPA-PSK/WPA2/WPA2-PSK), AES (WPA/WPA-PSK/WPA2/WPA2-
PSK)) or inactive (DISABLE).
