22
MSB = 20
MSB = 21
MSB = 22
MSB = 65
MSB = 66
MSB = 67
MSB = 68
MSB = 69, LSB = 0, 16, 17
MSB = 69, LSB = 1
MSB = 69, LSB = 2
MSB = 69, LSB = 3
MSB = 70
No. Parameter Display Value See Table Control
1 Delay Time 0.1mS – 400.0mS 0 – 127 table#7
2 Feedback Level -63 – +63 1 – 127
3 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
4 LPF Cutoff 1.0k – Thru 34 – 60 table#3
5
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1 Delay Time 64th/3 – 4thx6 0 – 19 table#14
2 Feedback Level -63 – +63 1 – 127
3 Feedback High Dump 0 – 1.0 0 – 10
4 L/R Diffusion 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
5 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
6
7
8
9
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11
12
13 EQ Low Frequency 32 – 2.0kH 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500 – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 Delay Time L>R 64th/3 – 4thx6 0 – 19 table#14
2 Delay Time R>L 64th/3 – 4thx6 0 – 19 table#14
3 Feedback Level -63 – +63 1 – 127
4 Input Select L, R, L&R 0 – 2
5 Feedback High Dump 0 – 1.0 0 – 10
6 Lag 1(-63ms) – 64(0ms) – 127(63ms) 1 – 127
7
8
9
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11
12
13 EQ Low Frequency 32 – 2.0kH 4 – 40
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500 – 16.0kHz 28 – 58
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2 LFO Depth 0 – 127 0 – 127
3 Feedback Level -63 – +63 1 – 127
4 Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15 Input Mode mono/stereo 0 – 1
16
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2 LFO Depth 0 – 127 0 – 127
3 Feedback Level -63 – +63 1 – 127
4 Delay Offset 0.0mS – 50mS 0 – 127 table#2
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124
15
16
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1
2 LFO Depth 0 – 127 0 – 127
3 Delay Offset 0.0mS – 50mS 0 – 127 table#2
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127 ●
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15
16
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ●
2 LFO Depth 0 – 127 0 – 127
3
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14
15
16
No. Parameter Display Value See Table Control
1 LFO Frequenct 0.0 – 39.7Hz 0 – 127 ●
2 LFO Depth 0 – 127 0 – 127
3
4
5
6 EQ Low Frequency 32 – 2.0kHz 4 – 40
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500 – 16.0kHz 28 – 58
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127
11
12
13
14 Drive 0 – 127 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127
No. Parameter Display Value See Table Control
1 LFO Frequenct 0.0 – 39.7Hz 0 – 127 ●
2 LFO Depth 0 – 127 0 – 127
3 AMP Type Off, Stack, Combo, Tube 0 – 3
4
5
6 EQ Low Frequency 32 – 2.0kHz 4 – 40
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500 – 16.0kHz 28 – 58
9 EQ High Gain -12 – +12dB 52 – 76
10 Dry/Wet Balance D63>W – D=W – D 1 – 127
11
12
13
14 Drive 0 – 127 0 – 127
15 LPF Cuttoff 1kHz – Thru 34 – 60
16 Output Level 0 – 127 0 – 127
No. Parameter Display Value See Table Control
1 LFO Frequency 0.00Hz – 39.7Hz 0 – 127 table#1 ●
2 AM Depth 0 – 127 0 – 127
3 PM Depth 0 – 127 0 – 127
4
5
6 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
7 EQ Low Gain -12 – +12dB 52 – 76
8 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
9 EQ High Gain -12 – +12dB 52 – 76
10
11 EQ Mid Frequency (*4) 100Hz – 10.0kHz 14 – 54 table#3
12 EQ Mid Gain (*4) -12 – +12dB 52 – 76
13 EQ Mid Width (*4) 1.0 – 12.0 10 – 120
14 LFO Phase Difference -180 – +180deg (resolution=3deg.) 4 – 124
15 Input Mode mono/stereo 0 – 1
16
