20 TOOLS for i88X/mLAN16E, Plug-in Effect Installation Guide
English
q Nickname
This field indicates the nickname of the
connected i88X. To change the nickname, refer
to “Node Information” in the mLAN Graphic
Patchbay Online Manual.
w Model Name
This parameter enables you to select an mLAN
device to which you wish to make an mLAN
connection in a multiple mLAN device network.
e [Update] button
Clicking this button updates the information on
the mLAN devices connected to the mLAN
network. Use this button when you add an
mLAN device to the network while mLAN Auto
Connector is running.
r [Identify] button
Clicking this button causes the i88X ACTIVE
indicator to flash for a few seconds.
t Sample Rate
This parameter enables you to specify the
sampling frequency (wordclock frequency).
y Wordclock Master radio buttons
These buttons enable you to specify the
computer or i88X as the wordclock master.
u PC → i88X
This parameter enables you to specify the
number of channels of audio data routed from
the computer’s audio output (mLAN driver’s
audio output) into the i88X. Signals input in the
i88X are output from the i88X’s OUTPUT 1-8
jacks (analog), DIGITAL STEREO COAXIAL
or OPTICAL OUT jack (digital), or ADAT OUT
jack (ADAT).
i [ASIO/WDM] button
Select the ASIO or WDM driver as appropriate
for your environment.
• With analog connections, WDM will use the last two of
the selected ASIO channels. The WDM channel sig-
nals will be output from OUTPUT 7 and 8.
o PC ← i88X
This parameter enables you to specify the
number of channels for audio data that is input
at the i88X’s INPUT 1-8 jacks (analog),
DIGITAL STEREO COAXIAL or OPTICAL
IN jack (digital), or ADAT IN jack (ADAT) and
output to the computer.
!0 [Connect] button
Click this button to connect the i88X to the
computer via mLAN.
!1 [Cancel] button
Click this button to cancel the settings and close
mLAN Auto Connector.
!2 [Setup] button
Click this button to open the i88X Control Panel
window, which enables you to set the wordclock
transition speed.
