4
OVEN & ACCESSORIES
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Turntable support
(17) 4 fixing screws (not shown).
• Place the turntable support in the seal packing on
the floor of the cavity.
• Then place the turntable on the turntable support.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or
authorised ZANUSSI service agent .
10
11
14
12
13
1 Front trim
2 Oven lamp
3 Control panel
4 Door opening button
5 Waveguide cover
6 Oven cavity
7 Seal packing
8 Door seals and sealing surfaces
9 Fixing points (4 points)
10 Ventilation openings
11 Outer cover
12 Rear cabinet
13 Power supply cord support clip
14 Power supply cord
15
16
1
2
3
4
5 6 7 8
9
