Prestige 2304 Support Notes

1. Trace LAN packet

1.1 Disable to capture the WAN packet by entering:

sys trcp channel enet1 none

1.2 Enable to capture the LAN packet by entering:

sys trcp channel enet0 bothway

1.3 Enable the trace log by entering:

sys trcp sw on

sys trcl sw on

1.4 Display the brief trace online by entering:

sys trcd brief

1.5 Display the detailed trace online by entering:

sys trcd parse

Example:

Prestige> sys trcp channel enet1 none

Prestige> sys trcp channel enet0 bothway

Prestige> sys trcp sw on

Prestige> sys trcl sw on

Prestige> sys trcd brief

0 11880.160 ENET0-R[0062] TCP 192.168.1.2:1108->192.31.7.130:80

1 11883.100 ENET0-R[0062] TCP 192.168.1.2:1108->192.31.7.130:80

2 11883.330 ENET0-T[0058] TCP 192.31.7.130:80->192.168.1.2:1108

3 11883.340 ENET0-R[0060] TCP 192.168.1.2:1108->192.31.7.130:80

4 11883.340 ENET0-R[0339] TCP 192.168.1.2:1108->192.31.7.130:80

5 11883.610 ENET0-T[0054] TCP 192.31.7.130:80->192.168.1.2:1108

6 11883.620 ENET0-T[0102] TCP 192.31.7.130:80->192.168.1.2:1108

7 11883.630 ENET0-T[0054] TCP 192.31.7.130:80->192.168.1.2:1108

8 11883.630 ENET0-R[0060] TCP 192.168.1.2:1108->192.31.7.130:80

9 11883.650 ENET0-R[0060] TCP 192.168.1.2:1108->192.31.7.130:80

10 11883.650 ENET0-R[0062] TCP 192.168.1.2:1109->192.31.7.130:80

Prestige> sys trcd parse

---<0000>----------------------------------------------------------------

LAN Frame: ENET0-RECV Size: 62/ 62 Time: 12089.790 sec

Frame Type: TCP 192.168.1.2:1116->192.31.7.130:80

Ethernet Header:

Destination MAC Addr = 00A0C5921311

Source MAC Addr = 0080C84CEA63

Network Type = 0x0800 (TCP/IP)
