Yamaha DPX-830 - Manual (Page 44)

40
◆ Composite / S-video signal specifications
Signal mode Resolution
(H × V)
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
Default mode for
16:9 screen
(H × V) *1
Default mode for
4:3 screen
(H × V) *2
Through mode
(H × V)
TV60 (525i) – 15.73 59.94 1280 Ч 720 1024 Ч 576 –
TV50 (625i) – 15.63 50.00 1280 Ч 720 1024 Ч 576 –
◆ Component signal specifications
Signal mode Resolution
(H × V)
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
Default mode for
16:9 screen
(H × V) *1
Default mode for
4:3 screen
(H × V) *2
Through mode
(H × V)
480i (525i) – 15.73 59.94 1280 Ч 720 1024 Ч 576 –
576i (625i) – 15.63 50.00 1280 Ч 720 1024 Ч 576 –
480p (525p) – 31.47 59.94 1280 Ч 720 1024 Ч 576 –
576p (625p) – 31.25 50.00 1280 Ч 720 1024 Ч 576 –
720p 60 (750p 60) – 45.00 60.00 1280 Ч 720 1024 Ч 576 –
720p 50 (750p 50) – 37.50 50.00 1280 Ч 720 1024 Ч 576 –
1080i 60 (1125i 60) – 33.75 60.00 1280 Ч 720 1024 Ч 576 –
1080i 50 (1125i 50) – 28.13 50.00 1280 Ч 720 1024 Ч 576 –
◆ Digital RGB / Component signal specifications
Signal mode Resolution
(H × V)
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
Default mode for
16:9 screen
(H × V) *1
Default mode for
4:3 screen
(H × V) *2
Through mode
(H × V)
480p (525p) – 31.47 59.94 1280 Ч 720 1024 Ч 576 –
576p (625p) – 31.25 50.00 1280 Ч 720 1024 Ч 576 –
720p 60 (750p 60) – 45.00 60.00 1280 Ч 720 1024 Ч 576 –
720p 50 (750p 50) – 37.50 50.00 1280 Ч 720 1024 Ч 576 –
1080i 60 (1125i 60) – 33.75 60.00 1280 Ч 720 1024 Ч 576 –
1080i 50 (1125i 50) – 28.13 50.00 1280 Ч 720 1024 Ч 576 –
VGA 60 640 Ч 480 31.47 59.94 960 Ч 720 1024 Ч 768 –
◆ Analog RGB signal specifications
Signal mode Resolution
(H × V)
Horizontal frequency
(kHz)
Vertical frequency
(Hz)
Default mode for
16:9 screen
(H × V) *1
Default mode for
4:3 screen
(H × V) *2
Through mode
(H × V)
576i (625i) *3 – 15.63 50.00 1280 Ч 720 1024 Ч 576 –
720p 60 (750p 60) – 45.00 60.00 1280 Ч 720 1024 Ч 576 –
720p 50 (750p 50) – 37.50 50.00 1280 Ч 720 1024 Ч 576 –
1080i 60 (1125i 60) – 33.75 60.00 1280 Ч 720 1024 Ч 576 –
1080i 50 (1125i 50) – 28.13 50.00 1280 Ч 720 1024 Ч 576 –
PC98 640 Ч 400 24.82 56.42 1152 Ч 720 1024 Ч 640 640 Ч 400
CGA70 640 Ч 400 31.47 70.09 1152 Ч 720 1024 Ч 640 640 Ч 400
CGA84 640 Ч 400 37.86 84.13 1152 Ч 720 1024 Ч 640 640 Ч 400
VGA60 640 Ч 480 31.47 59.94 960 Ч 720 1024 Ч 768 640 Ч 480
VGA72 640 Ч 480 37.86 72.81 960 Ч 720 1024 Ч 768 640 Ч 480
VGA75 640 Ч 480 37.50 75.00 960 Ч 720 1024 Ч 768 640 Ч 480
VGA85 640 Ч 480 43.27 85.01 960 Ч 720 1024 Ч 768 640 Ч 480
SVGA56 800 Ч 600 35.16 56.25 960 Ч 720 1024 Ч 768 800 Ч 600
SVGA60 800 Ч 600 37.88 60.32 960 Ч 720 1024 Ч 768 800 Ч 600
SVGA72 800 Ч 600 48.08 72.19 960 Ч 720 1024 Ч 768 800 Ч 600
SVGA75 800 Ч 600 46.88 75.00 960 Ч 720 1024 Ч 768 800 Ч 600
SVGA85 800 Ч 600 53.67 85.06 960 Ч 720 1024 Ч 768 800 Ч 600
XGA60 1024 Ч 768 48.36 60.00 960 Ч 720 1024 Ч 768 *4
XGA70 1024 Ч 768 56.48 70.07 960 Ч 720 1024 Ч 768 *4
XGA75 1024 Ч 768 60.02 75.03 960 Ч 720 1024 Ч 768 *4
XGA85 1024 Ч 768 68.68 85.00 960 Ч 720 1024 Ч 768 *4
MAC13 640 Ч 480 35.00 66.67 960 Ч 720 1024 Ч 768 640 Ч 480
MAC16 832 Ч 624 49.72 74.55 960 Ч 720 1024 Ч 768 832 Ч 624
MAC19 1024 Ч 768 60.24 75.02 960 Ч 720 1024 Ч 768 *4
SXGA60 1280 Ч 1024 60.02 63.98 900 Ч 720 960 Ч 768 *4
