1204 MIDI IMPLEMENTATION
1.TRANSMITTED DATA
NONE
2.RECOGNIZED DATA
1) CHANNEL VOICE MESSAGES
Table 1.
■
36
■
STATUS
SECOND
THIRD
DESCRIPTION
1011 nnnn
0ccc cccc
0vvv vvvv
CONTROL CHANGE
nnnn : MIDI Channel No.( 0000 1111 )
ccc cccc : Control No. ( See Table 1 )
vvv vvvv : Control Value ( See Table 1 )
1100 nnnn
0ppp pppp
---- ----
PROGRAM CHANGE
nnnn : MIDI Channel No.( 0000 1111 )
ppp pppp : Program No.( 000 0000 110 0011 )
Parameter
Control No.
Control Value.
Effect Pattern
84
Edit 1
85
Edit 2
86
EQ Low
87
EQ High
88
Mix Level
8
Effect ON/OFF
80,91
0 63=ON / 64 127=OFF
0 127
0 127
0 127
0 127
0 127
0 127
