Zoom 1204 - Manual (Page 10)

Connections
Connect an electronic instrument, microphone, mixer, or other audio equipment to the 1204 as described below.
Before making any connections, set the power switches of all equipment to OFF.
If the equipment is on, sudden noise surges can lead to hearing damage or damage
to the equipment.
