Xerox 8365/8390
Color Wide Format Printer
Print Engine
Print Speeds by Resolution and Print Mode
360 x 360 dpi, Quality—Production Speeds: •
2 x 4 (2xCMYK): 65–452 ft – 2 /hr (6–42 m 2 /hr)
360 x 720 dpi, Quality—Production Speeds: •
2 x 4 (2xCMYK): 62–245 ft – 2 /hr (5.7–22.6 m 2 /hr)
540 x 720 dpi, Quality—Production Speeds: •
2 x 4 (2xCMYK): 43–172 ft – 2 /hr (4–16 m 2 /hr)
720 x 720 dpi, Quality—Production Speeds: •
2 x 4 (2xCMYK): 32–140 ft – 2 /hr (3–13 m 2 /hr)
Printhead Technology
Piezo-electric Drop-on-Demand inkjet heads
with Dynamic Variable Dot Imaging Technology
(360 nozzles/color)
Ink
2 x 4 (2xCMYK) Mild-Solvent Ultra Ink •
440 ml cartridge –
Resolution
360 x 360, 360 x 720, 540 x 720, 720 x 720
Media Handling
Fully Motorized Winder/Unwinder 100, Foot Switch
and Feeder System with Media Cutter; supports both
2" (50.8 mm) and 3" (76.2 mm) core media and
single sheet
Max. Print Length
150' (45.72 m) •
Max. Print Width
8390: 88.5" (2,250 mm), 5 mm minimum margin •
8365: 64.6" (1,641 mm), 5 mm minimum margin •
Media Width Range
8390: Up to 89.76" (2,280 mm) •
8365: Up to 64.57" (1,653 mm) •
Media Thickness
0.00315–0.0433" (0.08–1.1 mm) •
Head Height
Automatic Media Thickness Compensation •
Built-In Heater
4 Digitally Controlled Heating Elements •
Interfaces
Ethernet TCP/IP 10/100 •
Media
Whatever your wide format printing needs, Xerox
has the media that will give you optimum results
from your printer:
Paper •
Banner Vinyl/Scrim •
Self-Adhesive Vinyl/PVC •
and much more •
Dimensions and Weight
Width, Depth, Height, Weight
8390 Wide Format Printer and Stand
145" (3,700 mm), 31" (787 mm), 49.2" (1,250 mm),
881 lbs. (400 kg)
8365 Wide Format Printer and Stand
122" (3,100 mm), 31" (787 mm), 49.2" (1,250 mm),
793 lbs. (360 kg)
Space Requirements
Height
78" (1,985 mm) clearance from floor to •
nearest overhead obstruction within the
floor space requirement
Width
8390 Model : 199.2" (5,060 mm) •
8365 Model: 183.3" (4,656 mm) •
Depth
99.5" (2,528 mm), 36" (914 mm) behind the •
printer is recommended for media loading
Environmental Requirements
Temperature
Minimum: 64º F/18º C •
Maximum: 80º F/27º C •
Relative Humidity (% RH non-condensing)
Minimum: 40% •
Maximum: 65% (no condensation) •
Air Purification System is required to maintain
air quality below acceptable safety levels.
Electrical Requirements
Single phase
2 wires plus safety ground •
Current
15 A •
Voltage
100–120 V +/-10% •
Frequency
50-60 Hz +/-10% •
Power Consumption
Standby
8390 Model: 100 W •
8365 Model: 80 W •
Printing
8390 Model: 1,400 W •
8365 Model: 1,300 W •
A 100–120 V/15A dedicated line should be used
for power.
RIP Software (Optional)
Xerox WFC Server Xerox WFC Server
RIP Pro v6.0 + RIP v6.0 +
ICC Profile Creation Yes No
ICC Profile Editing Yes Yes
Spot Color Mapping Yes Yes
Text Creation & Editing Yes No
Make Transparent Bitmap Yes No
Contour Cut Creation Yes No
& Editing
Variable Data
Yes No
Templates: Apply, Create, Yes No
& Edit
Tiling and Nest Pages
Yes Yes
Adobe ® PostScript ® 3™ Yes Yes
Print Direct from Yes Yes
Application
Mac
® and PC Support Yes Yes
Multiple Printer Support Up to 50 Up to 50
3 simultaneously 3 simultaneously
