Introduction
16 6218-I2 Wireless Router User’s Guide 6218-A2-ZB23-10
Rear Panel
Figure 2: Back Panel
The rear panel contains the ports for the router's data and power connections.
Table 2: Rear Panel Labels and Connectors
Label Function
LINE Connects to your ADSL line
LAN 1–4 Connects the router to Ethernet devices on your
LAN, such as your PC's Ethernet port, or the uplink
port on a hub or switch
RESET/DEFAULT To reset the router to its default settings
POWER Connects to the supplied power adapter
POWER ON/OFF
LAN4 LAN3 LAN2 LAN1
RESET
DEFAULT
LINE
CONSOLE
