8

11. Lubricate both axles on the Top Frame (55).

Slide the Right Arm (48) onto the right axle.
Be careful not to confuse the Right Arm
with the Left Arm (47); note the position of
the ÒVÓ Pulley (50) to identify the Right
Arm. Be sure that the upper end of the
Right Arm is behind the indicated bracket
on the Top Frame (55).

Tap two 1Ó Retainers (69) and a 1Ó Round
Cover Cap (70) onto the axle. Be sure that
the teeth on the Retainers bend toward the
Round Cover Cap, as shown in the inset
drawing.

Attach the Left Arm (47) in the same manner.

Press 1 3/4Ó Inner Caps (44) into the lower
ends of the Left and Right Arms (47, 48). Wet
the lower end of each Arm with soapy water.
Slide a 10Ó Pad (45) onto the lower end of
each Arm.

12. Press two 1Ó x 2Ó Inner Caps (87) into the

indicated end of the Squat Arm (84).

Attach the Squat Arm (84) to the VKR Upright
(74) with a 3/8Ó x 5 1/2Ó Bolt (93) and a 3/8Ó
Nylon Locknut (21). Be sure that the indicat-
ed bracket is pointing down as shown.

Wet the ends of the Squat Arm (84) with
soapy water. Slide the two Squat Arm Pads
(85) onto the Squat Arm.

Attach a Handle (82) to one side of the Squat
Arm (84) with a 5/16Ó x 2 1/2Ó Bolt (22), two
5/16Ó Flat Washers (8), a 1/2Ó x 17/32Ó Spacer
(91), and a 5/16Ó Nylon Locknut (3).

Wet the Handle (82) with soapy water. Slide a
5Ó Plastic Grip (83) onto the Handle. Press a
1Ó Round Inner Cap (49) into the other end of
the Handle.

Assemble another Handle (82) to the other
side of the Squat Arm (84) in the same man-
ner.

11

12

ARM ASSEMBL

Y

87

83

82

82

22

85

85

8

49

91

Bracket

84

93

21

3

74

69

70

AxleÑ

Lubricate

55

50

45

45

69

70

55ÑAxle

48

47

44

44

Bracket
